Samtec ESW Series Straight Through Hole PCB Socket, 2-Contact, 1 Row, 2.54 mm Pitch, 5.2A Current, 515V ESW-102-12-G-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 515V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 5.2A |
| Model | ESW-102-12-G-S |
| Mount Type | Through Hole |
| Housing Material | Black Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | ESW |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 2 |
| Connector System | Board-to-Board |
Key Features
- The socket features black glass filled polyester housing for enhanced durability.
- Contacts are made of phosphor bronze with gold plating for superior conductivity and corrosion resistance.
- Supports a rated current of 5.2 Amps and voltage of 515 Volts.
- Designed for through-hole mounting with straight orientation.
- Operates safely within a temperature range of -55°C to 125°C.
- Standard and low insertion force contacts provide ease of assembly.
- Compliance with RoHS standards ensures environmental safety.
- Suitable for industrial and electronic PCB assembly and prototyping.
Product Description
Samtec ESW-102-12-G-S is a high-quality straight through hole PCB Socket from the ESW series, designed for board-to-board electronic connections. It features 2 contacts arranged in a single row with a 2.54 mm pitch. The robust housing is made from black glass filled polyester, providing electrical insulation and mechanical strength.
The contacts are constructed from phosphor bronze and plated with gold to ensure reliable conductivity and corrosion resistance. This socket supports a current rating of 5.2 Amps and a voltage rating of 515 Volts, making it suitable for various industrial and electronic applications.
The socket employs standard and low insertion force contacts with standard solder tails, enabling straightforward through-hole mounting on PCBs. It operates efficiently within a temperature range from -55°C to 125°C, ensuring performance stability even in harsh environments.
Compliant with RoHS standards, this product ensures environmentally friendly manufacturing and use. Its straight orientation and board-to-board connector system facilitate seamless integration into complex electronic systems. Typical applications include industrial electronics assembly, manufacturing testing, prototyping, and other electronic component integration tasks.
The socket features black glass filled polyester housing for durability and insulation. Phosphor bronze contacts plated with gold deliver superior electrical performance. Rated current of 5.2 Amps and voltage of 515 Volts ensure robust operation.
Through-hole mount type with standard and low insertion force contacts. Operating temperature range of -55°C to 125°C for wide environmental tolerance. Single row, 2 contacts with a 2.54 mm pitch for precise board interconnects.
RoHS compliant, meeting environmental and safety standards. Ideal for industrial, manufacturing, and laboratory electronics applications. Explore more electronics components and PCB connectors in EnvMart’s extensive catalog to support your industrial, laboratory, and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a rated current of 5.2 Amps and a voltage of 515 Volts.
It features a pitch of 2.54 mm and has 2 contacts arranged in a single row.
The housing is constructed from black glass filled polyester, which provides electrical insulation and mechanical strength.
The contacts are made of phosphor bronze and are plated with gold for improved conductivity and corrosion resistance.
It operates efficiently within a temperature range of -55°C to 125°C.
This model is designed for through-hole mounting with standard solder tails, allowing for easy assembly on PCBs.
Yes, it is compliant with RoHS standards, ensuring environmentally friendly manufacturing and use.
It employs a board-to-board connector system, facilitating seamless integration into electronic systems.
The orientation of this socket is straight, designed for straightforward connections.
This socket is suitable for various applications including industrial electronics assembly, manufacturing testing, and prototyping.
The termination type for this model is solder, which is standard for through-hole connections.
The country of origin for this product is India.
