HARWIN M20 Series Straight Surface Pin Header 8 Contacts 2.54 mm Pitch 2 Row Unshrouded M20-8760442
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | HARWIN |
| Orientation | Straight |
| Current | 3A |
| Model | M20-8760442 |
| Mount Type | Surface |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | M20 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Mating Pin Length | 5.8mm |
Key Features
- The connector has 8 male contacts arranged in 2 rows for reliable connectivity.
- Pitch between pins is 2.54 mm, suitable for standard PCB designs.
- Made with durable nylon housing tolerating typical soldering temperatures.
- Gold-plated brass contacts ensure excellent conductivity and corrosion resistance.
- Unshrouded design allows easy mating with M20 series PCB sockets and jumpers.
- Mount type is surface mount, suitable for various electronics assembly processes.
- Operating temperature range extends from -40°C to 105°C for diverse environments.
- This product originates from Taiwan, Province Of China, and is new condition.
Product Description
The HARWIN M20-8760442 is a straight surface mount pin header designed for electronic components requiring reliable board-to-board and wire-to-board connections. It features 8 male contacts arranged in 2 rows with a 2.54 mm pitch, adhering to standard PCB interface dimensions.
The housing is constructed from high-temperature resistant nylon that can withstand solder reflow processes common in modern electronics manufacturing. The connectors are gold-plated brass, providing excellent signal integrity and resistance to corrosion.
This unshrouded pin header offers multiple configuration options and mates compatibly with M20 series PCB sockets, housings, and jumpers. The mating pin length of 5.8 mm ensures secure mechanical and electrical connections.
These headers are widely used in consumer electronics, communication devices, industrial monitoring systems, and embedded PCs. Their robust design supports operational temperatures from -40°C up to 105°C, allowing use in diverse environmental conditions.
The M20 series connectors are valued for their versatility and design flexibility, including options to be cut to custom sizes if necessary, while maintaining electrical performance.
The connector has 8 contacts arranged in 2 rows for board connections. 2.54 mm pitch aligns with industry standard PCB spacing. Durable nylon housing withstands reflow soldering temperatures. Gold-plated brass contacts ensure high conductivity and corrosion resistance.
Unshrouded design facilitates easy mating with compatible sockets. Surface mount type supports modern assembly techniques. Operational temperature range from -40°C to 105°C. Originates from Taiwan, Province Of China, ensuring quality manufacturing.
Select HARWIN M20 series connectors for reliable electronic assemblies in industrial, commercial, and consumer applications. Explore more components and detailed specifications on EnvMart for engineering design and procurement efficiency.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The contacts in this pin header have a pitch of 2.54 mm, which aligns with standard PCB spacing.
This model features 8 male contacts arranged in 2 rows for reliable connectivity.
The maximum operating temperature for this connector is 105°C, allowing it to function in diverse environments.
The housing is constructed from nylon, which is resistant to high temperatures typical in soldering processes.
It uses solder termination, which is standard for securing connections in electronic assemblies.
The mating pin length is 5.8 mm, ensuring secure mechanical and electrical connections.
This model has a current rating of 3A, suitable for various electronic applications.
This connector is unshrouded, which facilitates easy mating with compatible sockets and jumpers.
It supports board-to-board and wire-to-board connections, making it versatile for different applications.
This product originates from Taiwan, Province Of China, ensuring quality manufacturing standards.
It can operate in environments ranging from -40°C to 105°C, suitable for various industrial and consumer applications.
The orientation of this pin header is straight, designed for straightforward installation on PCBs.
