TDK B3560 Film Capacitor 2.2 nF 400V AC 630 V DC Through Hole 2 Lead Pitch 7.5mm B32560J8222K000

TDK B32560J8222K000 Film Capacitor is a high-quality passive electronic component designed for circuit applications requiring stable capacitance under varying electrical conditions.

Featuring a capacitance of 2.2 nF, it supports a rated AC voltage of 400V and a rated DC voltage of 630 V, making it suitable for demanding electronic circuits.

The capacitor is through-hole mounted with a lead pitch of 7.5 mm and a lead diameter of 0.5 mm, facilitating easy PCB integration. Its compact dimensions - length 9mm, height 5.5mm, and width 2.5mm - enable use in space-constrained layouts.

This capacitor complies with the automotive standard AEC-Q200 Rev D and meets RoHS requirements, ensuring it is environmentally friendly and reliable for automotive and industrial use.

Capable of operating at temperatures up to 125°C, it exhibits high pulse strength and durability making it an optimal choice for switched-mode power supplies (SMPS), converters, electronic ballasts, compact fluorescent lamps (CFL), and ignition systems.

The capacitor offers consistent performance in high-frequency switching circuits. Its robust design guarantees long life and minimal capacitance deviation. Special dimensions are available on request to fit customized applications.

Made in China with quality manufacturing processes. Designed to meet stringent international quality standards. This TDK Film Capacitor is ideal for industrial, automotive, and consumer electronics manufacturing, ensuring reliable electrical performance and long operational life.
