Wurth Elektronik 2538 Series PCB Terminal Block, 1-Contact, 10 mm Pitch, Through Hole Mount, 1 Row, 24A, 750V ac 691253800001

Wurth Elektronik 691253800001 is a PCB terminal block from the 2538 series, featuring a single contact and a 10 mm pitch. It is designed for through-hole mounting on printed circuit boards, offering reliable electrical connections with a vertical orientation. Rated for a current of 24A and a voltage tolerance of 750V ac, this component supports industrial and electronic applications requiring robust, high-quality connectors.

The terminal block accommodates wire sizes ranging from 0.05 mm² up to 3.31 mm² (corresponding to 30 AWG to 12 AWG), making it suitable for various wiring needs. Its green coloration assists with easy identification in complex PCB assemblies.

Physical dimensions are 18 mm in width, 5.6 mm in length, and 11.2 mm in depth, allowing engineers precise fitting within constrained PCB designs. The product is manufactured in Italy, ensuring high standards of production quality. It meets important certifications including cULus, RoHS, and VDE, assuring compliance with safety, health, and environmental standards.

This terminal block is widely used in industrial electronics, power and connector assemblies, and PCB-related electrical installations. Its modularity and reliable connection make it ideal for construction, manufacturing, and automated control systems requiring secure and maintainable electrical contacts.

Set contains one PCB terminal block with the specified features and mounting style. Ideal for replacing or designing high-reliability printed circuit board connections. Supports a current rating of 24 amperes at 750V ac voltage.

Single row configuration with one contact for compact PCB integration. Compatible with wire sizes from 0.05 mm² to 3.31 mm² (30 AWG to 12 AWG). Constructed with green color coding for easy identification. Mounting is through-hole ensuring secure mechanical and electrical connection.

Dimensions include 18 mm width, 5.6 mm length, and 11.2 mm depth for precise PCB layout. Complies with cULus, RoHS, and VDE standards ensuring safety and environmental compliance.
