Wurth Elektronik WR-TBL Series Pluggable Terminal Block, 6-Contact, 5.08 mm Pitch, 1 Row, 16A, Screwless 691304530006
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 2.5, 300kV ac |
| Brand | Wurth Elektronik |
| Colour | Green |
| Orientation | Vertical |
| Current | 16A |
| Length | 30.8mm |
| Depth | 10.6mm |
| Width | 26.2mm |
| Housing Material | Polyamide |
| Series | WR-TBL |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Number of Contacts | 6 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 0.13mm² |
| Maximum Wire Size mm² | 3.31mm² |
| Minimum Wire Size AWG | 26AWG |
| Maximum Wire Size AWG | 12AWG |
| Wire Connection Method | Screwless |
Key Features
- Constructed with durable polyamide housing material for reliable insulation.
- Designed with a vertical orientation and plastic latches for secure plug-in connection.
- Compatible with wire sizes ranging from 0.13 mm² to 3.31 mm² (26 AWG to 12 AWG).
- Rated for voltages up to 2.5 kV AC and 300 kV AC withstand voltage.
- Compact dimensions of 30.8 mm length, 26.2 mm width, and 10.6 mm depth.
- Green color coding for easy identification in assemblies.
- Ideal for industrial and electronic applications requiring pluggable terminal connectors.
Product Description
Wurth Elektronik 691304530006 WR-TBL Series Pluggable Terminal Block is a high-quality connector designed for industrial and electronic component applications. This pluggable terminal block features 6 contacts arranged in a single row with a pitch of 5.08 mm, providing reliable and efficient electrical connections.
The terminal block utilizes a screwless wire connection method, which allows for quick and tool-free installation while ensuring secure contact. Constructed from robust polyamide housing material, the unit provides excellent electrical insulation and mechanical durability.
Engineered with a vertical orientation for streamlined PCB mounting, this connector supports a current capacity of 16 amperes. It accommodates wire sizes from a minimum of 0.13 mm² (26 AWG) up to a maximum of 3.31 mm² (12 AWG), making it suitable for a broad range of wiring applications.
With voltage ratings up to 2.5 kV AC and a withstand voltage of 300 kV AC, it ensures safe operation in high-voltage environments. The compact form factor, measuring 30.8 mm in length, 26.2 mm in width, and 10.6 mm in depth, fits efficiently into circuit layouts while offering green color coding for easy identification.
This Pluggable Terminal Block is suitable for use in industrial automation, electronic manufacturing, power connectors assembly, and other laboratory or commercial electrical systems requiring modular and reliable connection solutions.
Constructed with durable polyamide housing for insulation and longevity. Provides screwless wire connection for fast, secure installation. Supports wire sizes from 0.13 mm² to 3.31 mm². Allows current capacity of up to 16 amperes.
Rated for voltages up to 2.5 kV AC and withstand voltage of 300 kV AC. Compact and vertically oriented design ideal for PCB mounting. Green color coding for identification in complex circuits.
Explore more industrial-grade electronic components and connectors in the Electronics & Electricals category on EnvMart. Wurth Elektronik products bring reliability and precision to your electrical assembly projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current capacity of up to 16 amperes.
It is rated for voltages up to 2.5 kV AC and has a withstand voltage of 300 kV AC.
This unit accommodates wire sizes ranging from 0.13 mm² (26 AWG) to 3.31 mm² (12 AWG).
The compact dimensions are 30.8 mm in length, 26.2 mm in width, and 10.6 mm in depth.
It utilizes a screwless wire connection method, allowing for quick and tool-free installation.
The housing is constructed from durable polyamide material, providing reliable insulation.
This model is designed with a vertical orientation for streamlined PCB mounting.
It features 6 contacts arranged in a single row with a pitch of 5.08 mm.
Yes, it features green color coding for easy identification in complex circuits.
It is suitable for industrial automation, electronic manufacturing, and power connector assemblies.
The country of origin for this product is China.
This product is part of the WR-TBL series of pluggable terminal blocks.
