KEMET R76_125C Film Capacitor, Through Hole, ±5 % Tolerance, 8.2 nF Capacitance, 2 kV DC and 700 V AC Rated R76UI182050H4J

KEMET R76UI182050H4J Film Capacitor is a premium electronic component designed for industrial and commercial applications requiring high reliability. This through-hole capacitor offers 8.2 nF capacitance with a tight tolerance of ±5 %, supporting operating voltages up to 2 kV DC and 700 V AC. It is constructed with polypropylene film and double metallized polyester film electrodes, ensuring stable performance and resilience against electrical stress.

Encapsulated in a self-extinguishing, solvent-resistant plastic case with thermosetting resin material, the capacitor withstands temperatures from -55°C up to 125°C, making it ideal for harsh environmental conditions including industrial power circuits and automotive electronics. The radial leads are electrically welded to metal layers on the winding ends, providing secure and durable connections for through-hole PCB mounting with a 15 mm lead pitch.

Compliant with IEC 60286-2 and RoHS directives, and meeting automotive AEC-Q200 standards, this capacitor is suitable for critical use in resonant and snubber circuits, silicon-controlled rectifier (SCR) and insulated gate bipolar transistor (IGBT) commutation circuits, as well as MOSFET silicon carbide (SiC) applications. Its low Equivalent Series Resistance (ESR) of 78 mΩ and dissipation factor of 0.1 % improve overall circuit efficiency and reliability.

The compact physical dimensions of 18 mm length, 6 mm width, and 12 mm height combined with solder-type terminals and 2-pin count offer convenient integration into various electronic assemblies. Lead diameter of 0.8 mm and lead length of 25 mm facilitate robust soldering connections for durability in manufacturing and operation.

This film capacitor offers high capacitance stability in the range of 100 pF to 15 μF for diverse electrical design needs. The capacitor’s temperature operating range from -55°C to 125°C ensures operational reliability in wide thermal environments.

Lead-free terminations and bag packaging support environmental and handling best practices. Its specifications support use in high-frequency and high-current circuits, including industrial and automotive applications. Designed with self-healing properties to maintain longevity and performance under electrical stress.

Suitable for use in industrial, laboratory, commercial, and automotive electronic manufacturing contexts, the KEMET R76UI182050H4J capacitor is a reliable choice for engineers seeking precision and durability in Film Capacitors. Explore more IEC-compliant, RoHS-certified passive components at EnvMart to find compatible electronic solutions.
