Wurth Elektronik WR-TBL Series Pluggable Terminal Block, 10-Contact, 5.08 mm Pitch, 1 Row, 16A, 2.5kV, Copper 691305530010
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 2.5kV |
| Brand | Wurth Elektronik |
| Colour | Green |
| Orientation | Vertical |
| Current | 16A |
| Length | 52.8mm |
| Depth | 8.6mm |
| Width | 12mm |
| Housing Material | Copper |
| Series | WR-TBL |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Standards/Approvals | cULus, REACH, RoHS |
| Number of Contacts | 10 |
| Connector Gender | Male |
| Wire Connection Method | Solder |
Key Features
- Constructed with durable copper housing for reliable conductivity.
- Features 10 contacts with a 5.08 mm pitch for efficient PCB connections.
- Single-row vertical orientation simplifies PCB assembly.
- Supports a current rating of 16 amperes suitable for moderate power applications.
- Rated for 2.5 kilovolts voltage ensuring electrical safety.
- Green color coding enables easy identification during installation.
- Wire connection via solder method provides secure and permanent joints.
- Certified to meet cULus, REACH, and RoHS standards for quality and environmental compliance.
Product Description
Wurth Elektronik 691305530010 Pluggable Terminal Block is engineered for reliable electrical connections in industrial and electronic PCB assemblies. It features 10 contacts configured in a single row with 5.08 mm pitch and a vertical orientation, designed specifically for solder wire connections ensuring stability and durability.
The terminal block's housing is made of copper, enhancing electrical conductivity and mechanical robustness. It is color-coded green, which helps technicians easily identify and manage wiring configurations on complex circuit boards.
Rated for a current capacity of 16A and voltage withstand of 2.5kV, this component adheres to stringent cULus, REACH, and RoHS certifications, ensuring that it meets safety, health, and environmental requirements necessary for professional electronic manufacturing.
Measuring 52.8 mm in length, 12 mm in width, and 8.6 mm in depth, this compact terminal block is suitable for use in electronics, power connectors, industrial automation, and PCB assembly applications. The WR-TBL series series offers plastic latches for secure mounting on PCBs, enhancing mechanical stability during installation and operation.
This product is manufactured in China under the Wurth Elektronik WR-TBL series, known for quality and reliability in electrical connector solutions. It is ideal for use in industrial control systems, automation machinery, and power distribution modules requiring dependable wire-to-board connections.
Constructed with durable copper housing for reliable conductivity. Features 10 contacts with a 5.08 mm pitch for efficient PCB connections. Single-row vertical orientation simplifies PCB assembly. Supports a current rating of 16 amperes suitable for moderate power applications.
Rated for 2.5 kilovolts voltage ensuring electrical safety. Green color coding enables easy identification during installation. Wire connection via solder method provides secure and permanent joints. Compact dimensions: Length 52.8 mm, Width 12 mm, Depth 8.6 mm.
Certified to meet cULus, REACH, and RoHS standards for quality and environmental compliance. Manufactured in China with consistent industrial quality standards.
Explore more high-quality Pluggable Terminal Blocks and electronic components at EnvMart for unmatched performance and reliability in your electrical projects and manufacturing processes.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 16 amperes, making it suitable for moderate power applications.
It is rated for a voltage withstand of 2.5 kilovolts, ensuring electrical safety in its applications.
This terminal block features 10 contacts, allowing for efficient connections in PCB assemblies.
The pitch size of this model is 5.08 mm, which is designed for effective PCB connections.
It measures 52.8 mm in length, 12 mm in width, and 8.6 mm in depth, making it compact for various applications.
The housing is constructed from copper, which enhances its electrical conductivity and mechanical robustness.
The wire connection is achieved via a solder method, providing secure and permanent joints.
It is certified to meet cULus, REACH, and RoHS standards, ensuring quality and environmental compliance.
This model features a vertical orientation, which simplifies PCB assembly.
It is manufactured in China, adhering to consistent industrial quality standards.
The connector gender of this unit is male, suitable for various applications in electronic assemblies.
It is suitable for use in electronics, power connectors, industrial automation, and PCB assembly applications.
