TDK Shielded Wirewound Surface Mount Inductor 47μH ±10%, 180mA Idc, 1210 Package, Ferrite Core, RoHS NLCV32T-470K-EF

TDK NLCV32T-470K-EF shielded wirewound surface mount inductor is a high-quality component designed for decoupling circuits and reducing electromagnetic interference in electronic assemblies. Its ferrite core and shielded construction ensure stable inductance and minimal signal distortion. The device features a 47μH inductance with a ±10% tolerance, supporting up to 180mA DC current, making it suitable for moderate power applications.

This inductor is housed in a compact 1210 package with precise dimensions of 3.2mm length, 2.5mm depth, and 2.2mm height, allowing for dense PCB layouts. It is rated for an operating temperature range from -40°C to +105°C, including consideration for self-temperature rise, ensuring durability in harsh environments.

The maximum DC resistance of 2.132 ohms contributes to energy efficiency, while the minimum quality factor of 15 ensures consistent performance at operating frequencies. With a maximum self-resonant frequency of 14MHz, this component supports applications requiring high-frequency operations.

The surface mount termination style facilitates automated manufacturing processes, increasing production efficiency. Its RoHS compliance guarantees adherence to international environmental and safety standards.

Typical industrial and commercial applications include smart meters, audiovisual devices, xDSL modems, telecommunications infrastructure equipment such as mobile base stations, and various industrial electronic systems requiring noise suppression and power conditioning.

The inductor employs a ferrite core for enhanced magnetic properties and shielding. Shielded wirewound construction minimizes electromagnetic interference. Compact 1210 package supports space-constrained PCB designs. Wide operating temperature range (-40 to 105°C) for reliable performance.

Surface mount termination compatible with pick-and-place assembly machines. RoHS certification ensures compliance with regulatory directives. Maximum DC current rating of 180mA for moderate load applications. Maximum DC resistance of 2.132Ω for energy efficiency.

Quality factor and self-resonant frequency ratings suitable for RF and signal circuits. Application versatility including smart meters and communication devices. Explore more Surface Mount Inductors and other high-performance electronic components within the TDK range at EnvMart.
