Nexperia Small Signal NPN Transistor 100 mA 45 V 3-Pin UMT Surface Mount BC850CW,115

Nexperia BC850CW,115 is a new small signal NPN transistor designed for surface mounting with a compact 3-pin UMT package. It supports a maximum DC collector current of 100 mA and collector emitter voltage up to 45 V, making it suitable for various electronic circuit applications requiring reliable switching and amplification.

This bipolar transistor features a high minimum DC current gain of 420, enabling efficient signal amplification with low distortion. Its maximum power dissipation rating of 200 mW ensures stable and safe operation under typical conditions, while the maximum transition frequency of 100 MHz allows use in high-frequency circuits.

Operating temperature ranges from -65°C to 150°C, making this transistor reliable in harsh automotive and industrial environments. The device complies with RoHS standards and conforms to AEC-Q101 automotive quality standards, ensuring extended reliability and performance consistency.

The transistor's compact footprint, with dimensions of 2.2 mm length, 1.35 mm width, and 1.1 mm height, is ideal for dense PCB layouts requiring space efficiency. The maximum collector base voltage of 50 V and emitter base voltage of 5 V provide versatility for a variety of circuit configurations.

This transistor suits industrial, automotive, communication, and consumer electronics applications where compact size and reliable signal processing are essential. Its surface mount package facilitates automated assembly and manufacturing efficiency.

Supports a maximum power dissipation of 200 mW for reliable operation. Has a minimum DC current gain (hFE) of 420 ensuring efficient amplification. Features a maximum transition frequency (ft) of 100 MHz suitable for high frequency applications.

Operates within a temperature range of -65°C to 150°C, ensuring stability under varied conditions. Complies with RoHS standards and meets automotive standard AEC-Q101 for quality assurance. Compact dimensions include length 2.2 mm, width 1.35 mm, and height 1.1 mm for space-saving PCB designs.

Maximum collector base voltage and emitter base voltage are 50 V and 5 V respectively for robust performance. Explore the wide selection of Bipolar Transistors including this model at EnvMart for your industrial and electronic component needs.
