Samtec IPT1 Series Straight Through Hole PCB Header, 20 Contacts, 2.54 mm Pitch, 2 Row, Shrouded

Samtec IPT1-110-01-S-D is a high-quality Straight Through Hole PCB Header featuring 20 individual contacts in a double row arrangement with a 2.54 mm pitch. This connector is engineered with a Liquid Crystal Polymer housing known for its robust mechanical and thermal properties, suitable for demanding industrial and electronic applications.

The male phosphor bronze contacts are plated with gold to provide exceptional electrical conductivity and resistance to corrosion, ensuring long-lasting and reliable signal integrity. Its shrouded design safeguards contacts during handling and mounting, enhancing connector performance and durability.

Operating temperature range from -55°C to 125°C makes it adaptable to a wide variety of environmental conditions commonly found in industrial, manufacturing, laboratory, and electronic system usage. The through-hole mounting method guarantees strong mechanical attachment to printed circuit boards and ensures stable electrical connections through soldering.

This PCB Header supports a current rating of 2.3 A and voltage up to 1.095 kV, making it suitable for moderate power electronics and signal transmission within control systems, instrumentation, and automation equipment.

The connector system is designed for board-to-board interfaces, common in embedded systems and complex electronic assemblies. Its 2-row, 20-contact configuration with 2.54 mm pitch complies with industry-standard dimensions, facilitating easy integration with numerous PCB layouts.

Liquid Crystal Polymer housing enhances durability and heat resistance. Gold-plated phosphor bronze contacts ensure high conductivity and corrosion protection. Suitable for harsh thermal environments from -55°C to 125°C.

Shrouded contact design protects pins and supports proper alignment. Through-hole mount type for robust mechanical and electrical connection. Current rating of 2.3 A accommodates moderate power requirements. Complies with 2.54 mm pitch and double row PCB design standards.

Male contact configuration designed for board-to-board connectivity. Voltage rating of 1.095 kV supports various electronic applications. Ideal for industrial, electronic manufacturing, laboratory, and automation uses. Explore more connectivity solutions and components with EnvMart’s comprehensive electronics catalog to suit your design and industrial requirements.
