Samtec IPT1 Series Straight Through Hole PCB Header, 10 Contacts, 2.54 mm Pitch, 2 Row, Shrouded

Samtec IPT1-105-01-S-D is a high-quality, dual-row, straight through-hole PCB header designed for robust electrical connections in electronic assemblies. This product features 10 gold-plated male contacts spaced at the industry standard 2.54 mm (0.100") pitch, mounted in a durable liquid crystal polymer shrouded housing. The shrouded design offers enhanced protection to contacts, reducing wear and insertion damage, and facilitating precise board-to-board mating.

This PCB header supports board-to-board connector systems and is rated for electrical currents up to 2.3 A and voltages reaching 1.095 kV, making it suitable for moderate power electronic applications. Its temperature tolerance ranges from -55°C to 125°C, allowing its use in demanding industrial, commercial, and laboratory environments.

The mounting style is through-hole, which ensures secure mechanical and electrical connection on printed circuit boards. The phosphor bronze contact material with gold plating guarantees excellent electrical performance and corrosion resistance, contributing to long-term reliability.

Liquid crystal polymer housing enhances mechanical stability. Gold-plated phosphor bronze male contacts provide excellent conductivity. Through-hole dual-row straight orientation allows versatile PCB integration. Shrouded contacts offer alignment and contact protection.

Rated for 2.3 A current and 1.095 kV voltage withstand. Wide operating temperature range (-55°C to 125°C) accommodates various environments. Ideal for industrial, electronic manufacturing, communication, and control systems.

Comprehensive technical design, combined with reliability and moderate power handling, makes this Samtec IPT1 series PCB Header an essential component in electronics manufacturing and engineering projects. Explore the full range of PCB connectors and headers on EnvMart to optimize your board design and assembly.
