Wurth Elektronik WR-TBL Series 4-Contact PCB Terminal Block Green 5 mm Pitch Through Hole 250V AC 24A 691137710004
Specifications
| Country of Origin | Italy |
|---|---|
| Voltage | 250V ac |
| Brand | Wurth Elektronik |
| Colour | Green |
| Orientation | Horizontal |
| Current | 24A |
| Length | 20mm |
| Depth | 11.5mm |
| Width | 7.5mm |
| Mount Type | Through Hole |
| Series | WR-TBL |
| Number of Rows | 1 |
| Pitch | 5mm |
| Standards/Approvals | VDE, RoHS, cULus |
| Number of Contacts | 4 |
| Minimum Wire Size mm² | 0.5mm² |
| Maximum Wire Size mm² | 4mm² |
| Minimum Wire Size AWG | 30AWG |
| Maximum Wire Size AWG | 12AWG |
| Wire guard material | Copper alloy with tin |
Key Features
- This terminal block has a green, horizontal orientation with 1 row configuration.
- Designed with copper alloy with tin wire guard material for reliable electrical connectivity.
- Supports wire sizes from 0.5 mm² to 4 mm² (30 AWG to 12 AWG).
- M2.5 screw size and 6 mm wire strip length ensure secure connections.
- Compact dimensions include 20 mm length, 7.5 mm width, and 11.5 mm depth for easy PCB integration.
- RoHS compliant with certifications including VDE and cULus.
- Operating temperature range from -30°C to +110°C supports diverse environments.
Product Description
Wurth Elektronik 691137710004 WR-TBL Series PCB Terminal Block is a high-quality electronic component designed for use in power and connector assemblies on printed circuit boards. This green, 4-contact terminal block has a 5 mm pitch and utilizes a through-hole mount suitable for horizontal PCB applications.
Operating at voltages up to 250V AC and with a maximum current rating of 24A, the terminal block provides safe and reliable connections for a wide range of electrical circuits. The device features a steel terminal screw with zinc plating and a wire guard made from copper alloy with tin, ensuring robust mechanical and electrical integrity.
Its compact form factor, measuring 20 mm in length, 7.5 mm in width, and 11.5 mm in depth, makes it ideal for space-constrained PCB layouts. The terminal block is designed for wire sizes from 0.5 mm² up to 4 mm², accommodating AWG30 through AWG12, and requires a wire strip length of 6 mm for optimal clamping.
Certified to international standards such as VDE and cULus, the WR-TBL Series meets the requirements of modern electronic assemblies, including compliance with RoHS directives for environmental safety. Its operating temperature ranges from -30°C to +110°C, making it suitable for industrial, laboratory, and commercial electronics environments.
This product provides 4 contact points for secure electrical connections. The 5 mm pitch spacing facilitates standard PCB mounting configurations. The through-hole mount style ensures strong mechanical support on the PCB.
The green color coding aids in easy identification in assemblies. Approved for use with 250V AC voltage and 24A current rating for effective power handling. Manufactured in Italy to high-quality standards. Ideal for industrial and electronic manufacturing applications that require reliable terminal blocks.
Explore the extensive range of Wurth Elektronik PCB Terminal Blocks on EnvMart for your next electronic design and fabrication project.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The terminal block supports a maximum voltage of 250V AC and a maximum current rating of 24A.
It accommodates wire sizes ranging from 0.5 mm² to 4 mm², which corresponds to AWG30 through AWG12.
This terminal block measures 20 mm in length, 7.5 mm in width, and 11.5 mm in depth.
The pitch of this terminal block is 5 mm, facilitating standard PCB mounting configurations.
It utilizes a through-hole mount style, providing strong mechanical support on the PCB.
The terminal block features a wire guard made from copper alloy with tin and a steel terminal screw with zinc plating.
It operates within a temperature range of -30°C to +110°C, suitable for diverse environments.
The terminal block is certified to VDE, RoHS, and cULus standards, ensuring compliance with international safety and environmental regulations.
This model features 4 contact points for secure electrical connections.
The terminal block is designed with a horizontal orientation, suitable for specific PCB layouts.
The optimal wire strip length for this terminal block is 6 mm, ensuring secure connections.
This terminal block is manufactured in Italy, adhering to high-quality standards.
