Wurth Elektronik WR-TBL Series 3-Contact 5 mm Pitch Horizontal PCB Terminal Block Through Hole 691137710003
Specifications
| Country of Origin | Italy |
|---|---|
| Voltage | 250V ac |
| Brand | Wurth Elektronik |
| Colour | Green |
| Orientation | Horizontal |
| Current | 24A |
| Length | 15mm |
| Depth | 11.5mm |
| Width | 7.5mm |
| Mount Type | Through Hole |
| Series | WR-TBL |
| Number of Rows | 1 |
| Pitch | 5mm |
| Standards/Approvals | VDE, RoHS, cULus |
| Number of Contacts | 3 |
| Minimum Wire Size mm² | 0.5mm² |
| Maximum Wire Size mm² | 4mm² |
| Minimum Wire Size AWG | 30AWG |
| Maximum Wire Size AWG | 12AWG |
| Wire guard material | Copper alloy with tin |
Key Features
- The component features a current rating of 24A for reliable power conduction.
- It supports wire sizes ranging from 0.5 mm² to 4 mm² and AWG 30 to AWG 12.
- The terminal block measures 15 mm in length, 7.5 mm in width, and 11.5 mm in depth.
- The wiring uses a pressure clamp mechanism with M2.5 steel screws plated with zinc.
- It operates up to 250V AC voltage with a contact resistance of 20 milliohms.
- The wire guard is made of copper alloy with tin plating for corrosion resistance.
- The product complies with VDE, RoHS, and cULus standards and operates from -30°C to +110°C.
Product Description
Wurth Elektronik 691137710003 WR-TBL Series PCB Terminal Block is designed for secure and efficient electrical connections in electronic and power connector applications. This horizontal, green-coloured 3-contact terminal block features a 5 mm pitch and is mounted through hole on printed circuit boards (PCB). It is engineered to handle currents up to 24A with excellent contact reliability and voltage rating of 250V AC.
Constructed with robust materials, the pressure clamp system incorporates steel terminal screws zinc-plated for durability and wire guard made from copper alloy with a tin finish for corrosion protection. The compact dimensions (15 mm length, 7.5 mm width, 11.5 mm depth) ensure space-efficient PCB layouts. Operating temperatures range from -30°C to +110°C, making it suitable for harsh industrial environments.
The terminal block supports wire sizes from a minimum of 0.5 mm² (30 AWG) up to 4 mm² (12 AWG), allowing flexible wire selection for diverse configurations. The M2.5 screw size ensures secure wiring connections. Compliance with VDE, RoHS, and cULus standards guarantee adherence to international safety and environmental norms.
This component is ideal for industrial electronics assembly, power distribution systems, automation control equipment, HVAC systems, and manufacturing machinery applications requiring reliable PCB wiring solutions.
24A current rating ensures safe power handling. Through-hole mount for secure PCB installation. Pressure clamp system with zinc-plated steel screws. Compact dimensions for efficient PCB space usage. Wire guard in copper alloy with tin plating for corrosion resistance.
Wide operating temperature range from -30°C to +110°C. RoHS and cULus compliance for environmental and safety standards. Select from the complete range of Wurth Elektronik terminal blocks and connectors at EnvMart for your next electronic project or industrial solution.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a current rating of 24A, ensuring reliable power conduction for various applications.
The terminal block operates at a voltage rating of 250V AC.
It supports wire sizes ranging from 0.5 mm² to 4 mm² and AWG 30 to AWG 12.
The terminal block measures 15 mm in length, 7.5 mm in width, and 11.5 mm in depth.
It is designed for through-hole mounting on printed circuit boards (PCB).
The terminal block features a pressure clamp mechanism with zinc-plated steel screws and a wire guard made of copper alloy with tin plating for corrosion resistance.
It operates effectively within a temperature range of -30°C to +110°C.
It complies with VDE, RoHS, and cULus standards, ensuring adherence to international safety and environmental norms.
This model features 3 contacts, allowing for multiple connections.
The terminal block has a pitch of 5 mm, which is standard for many PCB applications.
It is designed with a horizontal orientation for efficient PCB layout.
The country of origin for this terminal block is Italy.
