Nexperia Schottky Diode 60 V 1.4 A Surface Mount SOD-123W PMEG6010ETR,115
Specifications
| Country of Origin | Malaysia |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 2.8mm |
| Model | PMEG6010ETR,115 |
| Width | 1.9mm |
| Mount Type | Surface |
| Series | PMEG6010ETR |
| Maximum Operating Temperature | 175°C |
| Package Type | SOD-123W |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 1.4A |
| Peak Reverse Repetitive Voltage Vrrm | 60V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 50mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 50A |
| Maximum Forward Voltage Vf | 530mV |
| Peak Reverse Recovery Time trr | 4.4ns |
| Average forward current | IF(AV) ≤ 1 A |
| Reverse voltage | VR ≤ 60 V |
Key Features
- This diode features a maximum continuous forward current of 1.4 A.
- It supports a peak reverse repetitive voltage of 60 V.
- The device has a low maximum forward voltage of 530 mV, ensuring lower power losses.
- The package type is SOD-123W, ideal for compact surface mounting.
- It operates reliably in ambient temperatures from -55°C up to 175°C.
- The diode uses clip-bonding technology for high power capability.
- It provides extremely low leakage current and fast recovery time of 4.4 ns.
- The product adheres to the automotive standard AEC-Q101 for quality assurance.
Product Description
Nexperia PMEG6010ETR,115 Schottky Diode 60 V 1.4 A Surface Mount SOD-123W is designed for high efficiency and reliability in electronic circuits. It exhibits low forward voltage and low leakage current, making it highly suitable for low power consumption applications.
This diode features a high maximum continuous forward current rating of 1.4 A and withstands a peak reverse repetitive voltage of 60 V. Its SOD-123W plastic package ensures a small footprint while providing robustness and ease of surface mounting on printed circuit boards.
The device is rated for an operating temperature range from -55°C to 175°C, ensuring durability in demanding industrial, automotive, and electronic environments. Clip-bonding technology enhances power capability and thermal performance.
Typical applications include low voltage rectification, high efficiency DC-to-DC converters, switch mode power supplies, reverse polarity protection circuits, and other space-sensitive designs requiring reliable Schottky diode performance.
Maximum continuous forward current: 1.4 A. Peak reverse voltage: 60 V. Maximum forward voltage of 530 mV for energy efficiency. Fast peak reverse recovery time of 4.4 ns. Extremely low leakage current for reduced power losses.
Compliant with automotive standard AEC-Q101. Small and flat lead SOD-123W surface mount package. Wide operating temperature range from -55°C to 175°C. High power capability due to clip-bonding technology. Ideal for industrial, automotive, laboratory, and consumer electronics.
This product is manufactured in Malaysia and is supplied new to ensure quality and longevity. Explore more electronic components and semiconductors in the EnvMart catalogue for your design and manufacturing needs.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current rating of this diode is 1.4 A.
This model can withstand a peak reverse repetitive voltage of 60 V.
The maximum forward voltage of this Schottky diode is 530 mV.
It operates reliably in ambient temperatures from -55°C to 175°C.
The package type is SOD-123W, which is suitable for surface mounting.
The peak reverse recovery time is 4.4 ns.
The dimensions are 2.8 mm in length, 1.9 mm in width, and 1.1 mm in height.
It complies with the automotive standard AEC-Q101.
This model is a Schottky rectifier.
The peak non-repetitive forward surge current is 50 A.
The average forward current rating is less than or equal to 1 A.
The peak reverse current is 50 mA.
