Samtec ERM8 Series Straight Surface PCB Header 60 Contacts 0.8 mm Pitch 2 Row Shrouded ERM8

Samtec ERM8 Series Straight Surface PCB Header ERM8 is a high-performance board-to-board connector designed with 60 male contacts arranged in 2 rows with a precise 0.8 mm pitch.

Manufactured using Liquid Crystal Polymer housing and phosphor bronze contacts plated with gold, this shrouded connector delivers enhanced durability, corrosion resistance, and excellent electrical conductivity.

It supports a maximum operating current of 2.2A and voltage rating of 318V, making it suitable for demanding industrial electronics and communication applications.

Designed for surface mount technology with a straight connector orientation, the ERM8 header provides a secure solder termination method and rugged Edge Rate® contact design to ensure long-lasting performance and reliability.

This connector operates reliably in temperature environments ranging from -55°C to 125°C and offers stack height flexibility from 7.00 mm to 16.00 mm, accommodating various PCB assembly requirements.

Ideal for high-speed data transmission applications supporting transfer rates beyond 28 Gbps, the ERM8 series enables efficient and compact PCB connectivity.

Samtec ERM8 Series PCB Headers are commonly applied in industrial, telecommunications, computing, and manufacturing sectors where precise, reliable PCB connections are critical for system performance. These connectors are dual sourced by Hirose® and provide a final Inch® break out region for easy design integration.

Supports a current rating of 2.2A ensuring reliable electrical performance. Constructed with a housing made of Liquid Crystal Polymer for high strength and stability. Designed with phosphor bronze contacts plated in gold for excellent conductivity and corrosion resistance.

Suitable for surface mount applications with straight orientation and shrouded connector system. Operates efficiently within a temperature range of -55°C to 125°C for industrial environments. Offers a voltage rating of 318V meeting demanding PCB connectivity requirements.

Stack height ranges between 7.00 mm and 16.00 mm enabling flexible board-to-board spacing. Termination type is solder ensuring secure and stable mounting on PCBs. Male contact gender with a rugged Edge Rate® design for high-speed signal transmission up to 28+ Gbps.
