Samtec HTST Series Straight Surface PCB Header 10 Contact 2.54 mm Pitch 2 Row Shrouded HTST-105-01-T-DV

Samtec HTST-105-01-T-DV is a high-quality PCB header designed with 10 male contacts arranged in two rows with 2.54 mm pitch, ideal for wire-to-board connections in electronic assemblies. This straight, shrouded surface mount header features a housing made from liquid crystal polymer, providing excellent thermal stability and mechanical strength for industrial and commercial electronic applications.

The contact pins are fabricated from phosphor bronze and plated with tin, offering superior conductivity and corrosion resistance, critical for reliable long-term performance. It supports a current rating of 3.4A and a maximum operating temperature of 125°C, suitable for environments with variable thermal conditions.

Operating voltage is rated at 1kV, meeting safety requirements for robust electronic designs. The header works efficiently within a temperature range of -55°C to 125°C. Its 2-row, 10-contact configuration with a precise 2.54 mm pitch complies with standard PCB header dimensions, facilitating straightforward integration with compatible components and PCBs.

This component is manufactured in the United States and does not carry specific certifications or approvals. It is primarily used in electronics manufacturing, industrial equipment, instrumentation, and control systems requiring dependable PCB connectors.

The Samtec HTST series offers a range of pin counts and configurations, with polarization notches for secure and accurate mating. This product is ideal for applications demanding precision, durability, and electrical reliability in surface mount PCB Header connectors.

Supports a current rating of 3.4A ensuring stable electrical performance. Constructed with a liquid crystal polymer housing for high durability. Phosphor bronze contacts plated with tin for enhanced conductivity and corrosion resistance.

Designed with a straight orientation and surface mount termination type. Operates reliably within -55°C to 125°C temperature range. Wire-to-board connector system compatible with various PCB applications. Voltage rating up to 1kV for safe operation.

Manufactured in the United States to ensure quality standards. Explore more high-quality PCB connectors and related electronics components at EnvMart for industrial and commercial electronics manufacturing needs.
