TDK Standard Varistor 95 pF 360 A Clamping Voltage 775 V Varistor Voltage 220 V Package 1210 B72650M0141K072

TDK B72650M0141K072 standard varistor is a surface mount device designed to protect electronic circuits from voltage surges and transients. It features a 95 pF capacitance and a high clamping current of 360 A with a clamping voltage of 775 V. The device operates effectively with a nominal varistor voltage of 220 V, packaged in a compact 1210 SMD case.

This varistor is constructed with a ceramic material encapsulated in a flame-retardant plastic housing, ensuring safety and durability in demanding industrial and electronic applications. Its packaging is tape and reel, optimized for automated assembly processes.

The varistor tolerates a maximum AC voltage of 300 V and a maximum DC voltage of 385 V with a surge current capacity of up to 400 A, providing robust protection capabilities. It operates within a wide temperature range from -40°C to 85°C, suitable for diverse environmental conditions.

Compliance with international standards such as IEC 60068-2-58, UL, RoHS, JEDEC J-STD-020D, CECC 00802, and CSA ensures reliability and quality. The termination is made of tinned copper alloy, facilitating excellent solderability for surface mount applications.

Designed for surface mount device (SMD) assembly with ceramic construction. Capable of handling a maximum AC voltage of 300 V and DC voltage of 385 V. Maximum surge current rating of 400 A ensures robust surge protection.

Operates reliably within -40°C to 85°C temperature range. Encapsulated in flame-retardant plastic housing for safety. Complies with multiple standards including IEC, UL, RoHS, JEDEC, CECC, and CSA. Offers energy rating of 23 joules suitable for surge absorption.

Termination style uses tinned copper alloy for reliable soldering. Suitable for lead-free soldering processes and UL approved for voltages above 130 VRMS. Package size thickness 4.5 mm, length 8 mm, and depth 6.3 mm.

This varistor is widely used in industrial electronics, power supply surge protection, automotive electronics where burst and transient voltage suppression is critical. It supports accurate and reliable voltage regulation and protection for sensitive circuits.
