TDK Standard Metal Oxide Varistor 340 pF 100 A Clamping Voltage 2970 V Model B72220S0681K101
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 10mm |
| Brand | TDK |
| Material | Metal |
| THICKNESS | 8.4mm |
| Length | 21.5mm |
| Model | B72220S0681K101 |
| Depth | 26mm |
| Mount Type | Lead |
| Series | Standard |
| Energy Rating | 1J |
| Maximum Operating Temperature | 105°C |
| Capacitance | 340pF |
| Minimum Operating Temperature | -40°C |
| Maximum dc Voltage | 1465V dc |
| Standards/Approvals | CQC, CSA, UL, VDE, IEC |
| Pin Count | 2 |
| Lead Pitch | 10mm |
| Maximum AC Voltage | 1100V ac |
| Clamping Voltage VC | 2970V |
| Clamping Current | 100A |
| Maximum Surge Current | 6.5kA |
| Varistor Voltage | 1100 V |
Key Features
- Provides a varistor voltage of 1100 V for effective voltage regulation.
- Clamping voltage rated at 2970 V safeguards circuits during voltage spikes.
- Metal oxide material ensures durability and reliable performance.
- Operates reliably in temperatures from -40°C to 105°C.
- Lead mount type with two pins and a lead pitch of 10 mm for easy integration.
- Compact dimensions with 10 mm diameter and 21.5 mm length.
- Energy rating of 1 joule suitable for moderate surge absorption.
- Conforms to standards including CQC, CSA, UL, VDE, and IEC.
Product Description
TDK B72220S0681K101 is a high-performance Standard Metal Oxide Varistor designed for electronic surge protection applications. Featuring a capacitance of 340 pF and a varistor voltage of 1100 V, it provides effective voltage clamping and transient voltage suppression in circuits.
This model supports a clamping current of 100 A and a clamping voltage of 2970 V to protect sensitive electronic components from voltage spikes. Constructed with metal oxide material, it ensures stable electrical properties under harsh operating conditions.
With a stable operating temperature range from -40°C to 105°C, this varistor offers reliable performance in industrial, laboratory, and manufacturing environments. The component has a lead mount type configuration with two pins spaced at a 10 mm lead pitch, facilitating easy installation on printed circuit boards.
The varistor dimensions include a diameter of 10 mm, length of 21.5 mm, thickness of 8.4 mm, and total depth of 26 mm, making it a compact solution for space-constrained applications. It also features an energy rating of 1 joule, which is adequate for handling moderate surge energy.
Metal oxide construction for excellent surge protection. Compliant with international standards: CQC, CSA, UL, VDE, IEC. Flame-retardant coating enhances electrical safety and durability. Maximum AC voltage 1100 V, maximum DC voltage 1465 V suitable for various circuit designs.
Maximum surge current capacity of 6.5 kA accommodates severe transient events. Ideal for industrial, electronic components, and power protection systems. Standard series design offers proven reliability and ease of replacement.
This varistor is widely used in electronics manufacturing, power supply protection, electrical installations, and industrial surge mitigation systems. For further product exploration, browse the Varistor category on EnvMart to find compatible and complementary electronic components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The clamping voltage of this model is rated at 2970 V, which helps protect circuits during voltage spikes.
This varistor has a capacitance of 340 pF, suitable for effective voltage regulation.
The maximum surge current capacity of this unit is 6.5 kA, allowing it to accommodate severe transient events.
It operates reliably within a temperature range of -40°C to 105°C, making it suitable for various environments.
This varistor has a diameter of 10 mm, a length of 21.5 mm, a thickness of 8.4 mm, and a total depth of 26 mm.
It features a lead mount type configuration with two pins and a lead pitch of 10 mm for easy integration.
The energy rating of this varistor is 1 joule, which is adequate for handling moderate surge energy.
This varistor conforms to several standards including CQC, CSA, UL, VDE, and IEC.
The maximum AC voltage is 1100 V, and the maximum DC voltage is 1465 V, suitable for various circuit designs.
The clamping current rating is 100 A, which provides effective protection against voltage spikes.
It is constructed from metal oxide material, ensuring stable electrical properties under harsh conditions.
This model is widely used in electronics manufacturing, power supply protection, and industrial surge mitigation systems.
