Nexperia Bipolar Transistor NPN 100 mA 45 V 3-Pin SOT-23 BC850B,215

Name: Nexperia Bipolar Transistor NPN 100 mA 45 V 3-Pin SOT-23 BC850B,215
Brand: Nexperia
SKU: 145254
Price: 0.03 USD
Availability: InStock



Category Bipolar Transistors Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	1mm
Length	2.9mm
Model	BC850B,215
Width	1.3mm
Mount Type	Surface
Series	BC850B
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Pin Count	3
Maximum Collector Emitter Voltage Vceo	45V
Minimum DC Current Gain hFE	200
Transistor Polarity	NPN
Maximum Emitter Base Voltage VEBO	5V
Maximum Collector Base Voltage VCBO	50V
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	250mW
Maximum DC Collector Current Idc	100mA
Transistor Configuration	Single
ROHM BC847CHZGT116 Transistor, 100 mA NPN, 45 V, 3-Pin SOT-23Brand	ROHM

Key Features

The transistor supports a maximum power dissipation of 250 mW.
It features a minimum DC current gain (hFE) of 200.
Designed for surface mounting in electronic circuits requiring small signal amplification.
Operates over a temperature range from -65°C to 150°C.
Compatible with automotive applications meeting AEC-Q101 standard.
Single transistor configuration with NPN polarity ensures versatility in amplifier and switching circuits.
Package dimensions approximately 2.9 mm length, 1.3 mm width and 1 mm height.
Maximum emitter-base voltage rating is 5 V, with maximum collector-base voltage of 50 V.

Product Description

Nexperia BC850B,215 is a high-performance bipolar junction transistor (BJT) in an NPN configuration, designed for general purpose amplification and switching applications. The transistor has a maximum DC collector current of 100 mA and a maximum collector-emitter voltage of 45 V, enabling reliable operation in low-power electronic circuits.

Encased in a compact 3-pin SOT-23 surface mount package, this transistor is ideal for modern electronic devices where space savings and efficiency are crucial. It supports a maximum power dissipation of 250 mW and features a minimum DC current gain (hFE) of 200, ensuring effective signal amplification.

Operating across a wide temperature range from -65°C to 150°C, the BC850B,215 transistor meets automotive industry standards such as AEC-Q101, making it suitable for automotive and industrial electronics applications. Its dimensions (2.9 mm length x 1.3 mm width x 1 mm height) facilitate compact PCB layouts.

Key electrical ratings include a maximum emitter-base voltage of 5 V and a maximum collector-base voltage of 50 V. The transistor's single NPN polarity configuration suits a variety of amplification and switching tasks in circuits for consumer electronics, automotive control systems, and general industrial equipment.

The device supports surface mount technology (SMT) allowing efficient automated assembly. Ideal for signal amplification, switching, and general low power electronic applications. Complies with RoHS directive, ensuring environmental safety and compliance.

Available with detailed technical documentation and support for easy integration.

This transistor is a preferred choice for engineers developing compact and efficient electronic designs in industrial, consumer, and automotive sectors. Explore the wide range of Nexperia semiconductor components at EnvMart for compatible, reliable solutions.
