Molex CLIK-Mate Male Connector Housing 3 Way 1 Row Straight 2 mm Pitch 502439-0300

Molex 502439-0300 CLIK-Mate Male Connector Housing is a high-quality 3 Way, 1 Row Straight connector housing with a 2 mm pitch, intended for wire-to-board electronic connections with reliable mechanical and electrical performance.

The connector uses a robust Polybutylene Terephthalate material housing which provides excellent electrical insulation and mechanical protection. The dual inner positive locking mechanism ensures the connector securely mates with the housing, producing an audible click signal to verify proper connection assembly.

This model provides 3 contacts aligned in a single row spaced at 2 mm pitch. It is designed for cable mounting and is compatible with Molex 502438 crimp terminals, which are required to complete the connector assembly but sold separately.

Additional design features include polarization and mating guides, which prevent incorrect mating and ensure connector reliability in high-vibration or industrial usage. The compact dimensions of 10 mm length and 9.65 mm width make it suitable for space-constrained applications.

Typical use cases for this connector housing include automotive headlamps, interior vehicle mirrors, industrial scanning devices, smart grid meters, LED lighting modules, medical patient monitoring systems, surgical equipment, and LCD and TV panels. It supports a robust wire-to-board connection system capable of 3.0 A current rating and up to 250 V.

Dual inner positive locking mechanism for reliable secure mating. Made from durable Polybutylene Terephthalate housing material. 3 contact, 1 row straight male housing with 2 mm pitch spacing. Polarized design to prevent mismating and ensure correct assembly.

Compatible with 502438 Molex crimp terminals (sold separately). Compact 10 mm length and 9.65 mm width dimensions. Ideal for automotive, industrial, medical, and consumer electronics applications.

Molex CLIK-Mate connectors are well-regarded in industrial and electronics manufacturing for providing reliable, low insertion force connections with secure locking features, suitable for harsh environments and demanding usage scenarios.

Explore the complete range of Molex CLIK-Mate Connector Housings and accessories on EnvMart to fulfill your electronic assembly needs with trusted quality and industry-standard designs.
