XP Power 6W Isolated Dual Output Through Hole DIP DC/DC Converter 15V 200mA 18-36V Input JCD0624D15

XP Power JCD0624D15 is a 6W isolated dual output DC/DC converter designed for industrial and electronic applications requiring stable voltage conversion and isolation. It features a 2:1 input voltage range allowing operation between 18V and 36V dc, providing a regulated 15V dc output at 200mA. The through hole DIP package facilitates robust and easy through-hole PCB mounting. Offering an isolation voltage of 1.6 kV dc, it ensures enhanced electrical isolation between input and output circuits, which is critical in sensitive control and measurement environments.

This converter operates efficiently at up to 83%, reducing power losses and heat generation. Its wide temperature operating range from -40°C to +100°C makes it suitable for harsh industrial and environmental conditions. The product includes continuous short circuit protection, improving durability and reliability in demanding installations.

The compact physical dimensions (31.75mm length, 20.32mm width, and 10.4mm depth) make it ideal for constrained spaces on printed circuit boards. The JCD series converters by XP Power comply with RoHS standards, ensuring environment-friendly manufacturing and operation.

The high MTBF rating of 1.1 million hours underscores the product’s reliability for long-term industrial use. Typical uses include power supplies in control systems, instrumentation circuits, telecommunications equipment, and embedded electronics requiring galvanic isolation and regulated power delivery.

The converter offers a 2:1 input voltage range from 18V to 36V dc. Output voltage is 15V dc with a current rating of 200mA suitable for low power applications. Compact through hole DIP package ensures easy board mounting with a standard footprint.

High isolation voltage of 1.6 kV dc enhances safety and noise immunity. Wide operating temperature range from -40°C to 100°C allows reliable performance in harsh environments. Efficiency is rated up to 83% ensuring low heat dissipation and energy savings.

Features continuous short circuit protection for enhanced durability. Apply in industrial power supplies, instrumentation, and electronic component designs requiring isolated regulated voltages. MTBF is approximately 1,100,000 hours, ensuring dependable operation.

Dimensions are compact: length 31.75mm, width 20.32mm, depth 10.4mm. Designed and manufactured with compliance to RoHS standards. Explore more DC/DC Converters and related power supply solutions on EnvMart to find components that match your electronic design needs.
