XP Power 10 W Isolated Through Hole DC/DC Converter 500V DC Output 20 mA, 12V DC Input F05

XP Power F05 DC/DC Converter is an isolated 10 W power supply module designed for converting low voltage DC inputs to high voltage DC outputs with exceptional stability and robustness. It features a 500V DC output at 20 mA and accepts inputs from 0 V up to a maximum of 12 V DC. The converter utilizes a through hole mounting style and is housed in a compact ComPacT package measuring 71.1 mm in length, 43.2 mm in width, and 21.6 mm in depth, making it suitable for applications with space constraints.

Operating from -10 °C to a maximum of 70 °C, this DC/DC converter is suited for industrial, laboratory, and electronic equipment environments where reliable power isolation and voltage conversion are critical. The high isolation voltage of 3.5 kV ensures safety and noise immunity between input and output circuits.

Key functional features include very low ripple and noise output (0.1%), short circuit protection, no minimum load requirements, and proportional input/output behavior to maintain steady power delivery. The robust construction supports a Mean Time Between Failures (MTBF) of approximately 810,000 hours, demonstrating long operational life and trusted reliability.

This model is ideal for applications such as capacitor charging, igniter and spark modules, piezoelectric device driving, field generation, and other specialized uses requiring isolated high voltage DC power from a DC source. It represents an efficient, compact, and reliable solution in rugged environments.

Low ripple and low EMI/RFI output ensures clean power delivery. Short circuit protection prevents damage under fault conditions. Compact through hole design facilitates integration into PCB assemblies. High isolation voltage enhances safety and interference immunity.

Wide operating temperature range supports diverse environmental conditions. Proven reliability with MTBF above 800,000 hours. No minimum load required simplifies design specifications. ComPacT package aids space-saving electronic designs.

Suitable for capacitor charging, ignition, piezo devices, and field generation.
