XP Power EMI IEC Filter 264V AC 10A Screw Mount Faston Termination Male with 1 Fuse FASMA10SFR

Free Delivery in India | Lowest Global Shipping Charges

XP Power EMI IEC Filter 264V AC 10A Screw Mount Faston Termination Male with 1 Fuse FASMA10SFR

Name: XP Power EMI IEC Filter 264V AC 10A Screw Mount Faston Termination Male with 1 Fuse FASMA10SFR
Brand: XP Power
SKU: 421806
Price: 20.22 USD
Availability: InStock



Category IEC Filters Brand XP Power Condition New

Specifications

Country of Origin	China
Voltage	264V ac
Brand	XP Power
Current	10A
Height	22.5mm
Model	FASMA10SFR
Filter Type	EMI
Depth	58mm
Width	50.4mm
Mount Type	Screw
Operating Frequency	400Hz
Series	XXX
Termination Type	Faston
Maximum Operating Temperature	110°C
Minimum Operating Temperature	-40°C
Contact Gender	Male
Connector Gender	Male
Fuse Size	5 x 20 mm
Number of Fuses	1
IEC Connector Type	IEC 320 C14

Key Features

The filter contains a single 5 x 20 mm fuse for overcurrent protection.
Engineered for use in medical and industrial equipment to minimize electromagnetic interference.
Features a shielded metal body and bleed resistor to discharge filter capacitors safely.
Operates effectively across a wide temperature range of -40°C to 110°C.
IEC 320 C14 male connector ensures reliable mains connection.
Compact dimensions of 22.5mm height, 50.4mm width, and 58mm depth fit in constrained spaces.
Faston termination enables secure and easy installation.
Provides excellent attenuation of conducted EMI and low earth leakage current.

Product Description

XP Power FASMA10SFR is an EMI IEC filter engineered to provide superior attenuation of conducted electromagnetic interference on mains power supplies. Operating at 264V AC with a current rating of 10A, this device combines an EMI filter with an inlet, ideal for medical and industrial equipment applications requiring reliable EMI suppression.

This model incorporates a single 5 x 20 mm fuse and features a shielded metal body, ensuring robust protection and minimal EMI leakage to mains. The faston termination type and screw mount allow for convenient installation and secure connections. It uses an IEC 320 C14 male connector, widely compatible with standard power inputs.

The FASMA10SFR maintains excellent performance over an operating frequency of 400Hz and tolerates temperatures from -40°C to 110°C, supporting operation up to 50°C at full power. A built-in bleed resistor safely discharges capacitors when power is disconnected, enhancing safety and longevity.

Compactly sized at 22.5 mm in height, 50.4 mm in width, and 58 mm in depth, the filter is well-suited for integration into class I appliances, providing effective mains interference attenuation while complying with rigorous quality standards.

The filter features EMI suppression ideal for sensitive industrial and medical equipment. Designed for class I appliances with screw mounting for secure fixing. Low earth leakage current of 5μA at 250VAC makes it suitable for medical use.

Robust metal shielded body enhances durability and EMI protection. Wide temperature operating range expands applicability across environments. Faston termination optimizes connectivity and installation speed. Integral bleed resistor ensures safe capacitor discharge post power-off.

Inlet filter combination provides compact and effective noise reduction.

This IEC filter is ideal for industrial, medical, laboratory, and commercial equipment requiring high-quality EMI filtration. The combination of technical features and build quality ensures reliable performance in demanding environments.
