XP Power IEC Filter 264V AC 3A Screw Mount Male Connector with 1 Fuse FASMA03SFR

Free Delivery in India | Lowest Global Shipping Charges

XP Power IEC Filter 264V AC 3A Screw Mount Male Connector with 1 Fuse FASMA03SFR

Name: XP Power IEC Filter 264V AC 3A Screw Mount Male Connector with 1 Fuse FASMA03SFR
Brand: XP Power
SKU: 421802
Price: 20.22 USD
Availability: InStock



Category IEC Filter Brand XP Power Condition New

Specifications

Country of Origin	China
Voltage	264V ac
Brand	XP Power
Current	3A
Height	22.5mm
Model	FASMA03SFR
Filter Type	EMI
Depth	58mm
Width	50.4mm
Mount Type	Screw
Operating Frequency	400Hz
Series	XXX
Termination Type	Faston
Maximum Operating Temperature	110°C
Minimum Operating Temperature	-40°C
Contact Gender	Male
Connector Gender	Male
Fuse Size	5 x 20 mm
Number of Fuses	1
IEC Connector Type	IEC 320 C14

Key Features

Combines an EMI filter and inlet for effective conducted interference attenuation.
Features a low earth leakage current of 5μA at 250VAC for medical equipment compliance.
Shielded metal body with a bleed resistor to safely discharge capacitors.
Supports operating temperatures from -40°C to +110°C with full power up to +50°C.
Includes a 5 x 20 mm fuse rated at 3A for circuit protection.
IEC 320 C14 male connector type with screw mounting for secure installation.
Termination via 6.3 x 0.8 mm Faston terminals for reliable electrical connection.
Compact dimensions of 50.4mm width, 22.5mm height, and 58mm depth.

Product Description

XP Power FASMA03SFR IEC Filter is a compact EMI filter module designed to combine efficient conducted electromagnetic interference attenuation with an integrated inlet. It operates at 264V AC and supports a current rating of 3A. The filter is equipped with a single 5 x 20 mm fuse for added circuit protection.

This filter incorporates a low earth leakage current of 5μA at 250VAC, making it suitable for medical equipment applications requiring stringent leakage standards. The unit features a shielded metal body which ensures effective EMI suppression while reducing conducted emissions from connected equipment back onto the mains supply.

The FASMA03SFR model has screw mount installation and uses IEC 320 C14 male connectors with Faston termination of size 6.3 x 0.8 mm, allowing for reliable and secure electrical connections. It operates within a temperature range of -40°C to +110°C, supporting continuous full power operation up to +50°C, making it suitable for diverse industrial and commercial environments.

The compact physical size with dimensions 50.4mm width, 22.5mm height, and 58mm depth allows it to fit into tight spaces within mains powered equipment. The integrated bleed resistor ensures safety by discharging filter capacitors upon power disconnection.

This IEC filter module is applicable in various sectors including medical devices, industrial manufacturing equipment, and commercial electronics where EMI attenuation is crucial. Its design complies with common operational standards though no specific certifications are listed. Manufactured in China, the XP Power FASMA03SFR offers dependable performance in demanding EMI filtering applications.

Combines EMI filter and inlet for conducted interference attenuation. Low earth leakage current suitable for medical equipment applications. Shielded metal body with bleed resistor for capacitor discharge. Screw mount with IEC 320 C14 male connector.

Single 5 x 20 mm fuse rated at 3A included. Faston termination for secure electrical connections. Wide operating temperature range from -40°C to +110°C. Compact dimensions for easy equipment integration. Suitable for industrial, medical, and commercial mains powered devices.
