XP Power Isolated DC/DC Converter 15V DC 130mA Output 13.2V-10.8V Input 2W Through Hole IL1215S
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power IL DC/DC Converter, 15V dc/ 130 mA, 13 |
| Brand | XP Power |
| Efficiency | 84% |
| Length | 11.68mm |
| Model | IL1215S |
| Depth | 10.16mm |
| Width | 7.5mm |
| Mount Type | Through Hole |
| Series | IL |
| Maximum Operating Temperature | 100°C |
| Package Type | SIP |
| Minimum Operating Temperature | -20°C |
| MTBF | 1210000h |
| Number of outputs | 1 |
| Maximum Output Power | 2W |
| Maximum Input Voltage | 13.2V dc |
| Minimum Input Voltage | 10.8V |
| Number of Pins | 4 |
| Output Voltage 1 | 15V dc |
| Output Current 1 | 130mA |
| Isolation Voltage | 1kV dc |
Key Features
- Provides isolated 2W power supply from 10.8V to 13.2V input voltage range.
- Implements through hole mounting in a compact SIP package.
- Features high efficiency of up to 84% for energy saving.
- Operating temperature range from -20°C to 100°C ensures durability.
- Offers 1 kV DC isolation voltage for safety and noise reduction.
- Built with 4 pins and small dimensions suitable for PCB integration.
- Mean time between failure (MTBF) rated at 1,210,000 hours for reliability.
- Ideal for industrial, electronic components, power supply, and voltage conversion applications.
Product Description
XP Power IL1215S is an isolated DC/DC converter delivering a regulated 15V DC output voltage with 130mA output current. Designed for efficient power conversion, it accepts input voltages from 10.8V up to 13.2V DC, making it suitable for varied low-voltage power applications.
The device features a through hole mount SIP package with compact dimensions of 11.68mm length, 10.16mm depth, and 7.5mm width, facilitating easy PCB integration. With an efficiency up to 84%, it ensures minimal energy loss during conversion.
This DC/DC converter supports a wide operating temperature range from -20°C to 100°C, enabling usage in demanding industrial environments. The unit provides an isolation voltage of 1kV DC enhancing electrical safety and minimizing noise interference.
XP Power IL series converters have a high mean time between failure (MTBF) of approximately 1,210,000 hours, indicating exceptional reliability and long operational life. The device has four pins for mounting and connectivity.
This product suits applications including industrial power supplies, voltage regulation, telecommunications, and embedded electronics requiring compact, efficient, and reliable DC power conversion.
Provides isolated 2W power supply from 10.8V to 13.2V input voltage range. Implements through hole mounting in a compact SIP package. Features high efficiency of up to 84% for energy saving. Operating temperature range from -20°C to 100°C ensures durability.
Offers 1 kV DC isolation voltage for safety and noise reduction. Built with 4 pins and small dimensions suitable for PCB integration. Mean time between failure (MTBF) rated at 1,210,000 hours for reliability. Compact size: 11.68mm length x 10.16mm depth x 7.5mm width.
Ideal for industrial, electronic components, power supply, and voltage conversion applications. Explore a wide range of DC/DC Converters and power supply solutions on EnvMart for your industrial and electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The XP Power IL1215S provides a regulated output voltage of 15V DC with an output current of 130mA.
It accepts input voltages ranging from 10.8V to 13.2V DC.
This model features an efficiency of up to 84%, ensuring minimal energy loss during conversion.
The dimensions of this unit are 11.68mm in length, 10.16mm in depth, and 7.5mm in width.
It offers an isolation voltage of 1kV DC, enhancing electrical safety and minimizing noise interference.
The operating temperature range is from -20°C to 100°C, making it suitable for demanding environments.
It implements through hole mounting in a compact SIP package, facilitating easy PCB integration.
The mean time between failure (MTBF) is rated at approximately 1,210,000 hours, indicating high reliability.
This converter has one output.
It is ideal for applications including industrial power supplies, voltage regulation, telecommunications, and embedded electronics.
The unit comes in a SIP package type, which is compact and suitable for PCB integration.
This model belongs to the IL series of XP Power DC/DC converters.
