Wurth Elektronik 5081 Series PCB Terminal Block, 4-Contact, 3.5 mm Pitch, Through Hole Mount, Horizontal, 300V 691508110304

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik 5081 Series PCB Terminal Block, 4-Contact, 3.5 mm Pitch, Through Hole Mount, Horizontal, 300V 691508110304

Name: Wurth Elektronik 5081 Series PCB Terminal Block, 4-Contact, 3.5 mm Pitch, Through Hole Mount, Horizontal, 300V 691508110304
Brand: Wurth Elektronik
SKU: 140360
Price: 4.04 USD
Availability: InStock



Category PCB Terminal Block Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Voltage	300V ac
Brand	Wurth Elektronik
Colour	Black
Orientation	Horizontal
Current	10A
Length	16mm
Depth	12.2mm
Width	17.6mm
Mount Type	Through Hole
Series	5081
Number of Rows	1
Pitch	3.5mm
Standards/Approvals	VDE, RoHS, cULus
Number of Contacts	4
Minimum Wire Size mm²	0.05mm²
Maximum Wire Size mm²	1.33mm²
Minimum Wire Size AWG	30AWG
Maximum Wire Size AWG	16AWG

Key Features

Rated for a current of 10A at 300V AC voltage.
Compatible with wire sizes from 30 AWG to 16 AWG (0.05 mm² to 1.33 mm²).
Constructed with a pressure clamp system using M2 screws and tin plated brass clamps for secure connections.
Housing made from grey UL94-V0 LCP material featuring alignment pegs for precise PCB positioning.
Meets standards including VDE, RoHS, and cULus for quality and safety compliance.

Product Description

Wurth Elektronik 691508110304 5081 Series PCB Terminal Block is a high-quality electrical connector designed for printed circuit boards, featuring 4 contacts and a 3.5 mm pitch. This terminal block is tailored for through hole mounting with a horizontal orientation, supporting industrial, electronic, and manufacturing applications where reliable electrical connection and safety are paramount.

It features a pressure clamp system with M2 screws and tin plated brass clamps ensuring a secure and robust connection to solid or stranded wires ranging from 30 AWG to 16 AWG (0.05 mm² to 1.33 mm²). The housing is molded from grey UL94-V0 rated Liquid Crystal Polymer (LCP) material providing high flame resistance and durability in demanding environments.

This component has a compact form factor with dimensions measuring 16 mm in length, 17.6 mm in width, and 12.2 mm in depth. It is rated for electrical loads of up to 10A at 300V AC voltage, making it suitable for a range of electronic devices and power distribution systems.

Designed with alignment pegs on the housing, it facilitates precise positioning during PCB soldering and assembly processes. The product complies with recognized international standards including VDE, RoHS, and cULus, guaranteeing adherence to environmental and electrical safety requirements.

This 1-row terminal block from the Wurth 5081 series is a reliable solution for electronics manufacturing, industrial equipment assembly, laboratory instruments, and HVAC control systems requiring stable and safe wire-to-board connections.

Rated for a current of 10A at 300V AC voltage. Compatible with wire sizes from 30 AWG to 16 AWG (0.05 mm² to 1.33 mm²). Constructed with a pressure clamp system using M2 screws and tin plated brass clamps for secure connections.

Housing made from grey UL94-V0 LCP material featuring alignment pegs for precise PCB positioning. Dimensions: Length 16mm, Width 17.6mm, Depth 12.2mm. Meets standards including VDE, RoHS, and cULus for quality and safety compliance.
