Panasonic ECWFE Metallised Polypropylene Film Capacitor 220 nF ±5% 630 V dc Radial Through Hole ECWFE2J224J
Specifications
| Country of Origin | China |
|---|---|
| Brand | Panasonic |
| Height | 12.5mm |
| Length | 17.5mm |
| Model | ECWFE2J224J |
| Packaging | Bag |
| Width | 7mm |
| Mount Type | Through Hole |
| Series | ECWFE |
| Maximum Operating Temperature | 105°C |
| Tolerance | ±5 % |
| Capacitance | 220nF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Radial |
| Dissipation Factor | 0.1% |
| Lead Length | 20mm |
| Rated DC Voltage | 630V dc |
| Lead Pitch | 15mm |
| Lead Diameter | 0.6mm |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with metallised polypropylene dielectric for superior electrical performance.
- Features a flame retardant, non-combustible epoxy resin case for flame safety.
- Built-in fuse functionality ensures failsafe operation by opening circuit on failure.
- Designed for vibration resistance with a compact robust boxed exterior.
- Operates reliably between -40°C and 105°C temperature range.
- Lead pitch is 15 mm with radial terminal type and 20 mm lead length.
- Compliant with automotive standard AEC-Q200 and UL/EN/CSA approvals.
- Ideal for active filter and high frequency circuits in industrial automation and IT applications.
Product Description
Panasonic ECWFE2J224J is a metallised polypropylene film capacitor with 220 nF capacitance, ±5% tolerance, and rated for 630 V dc applications. It features a radial through hole mount with 15 mm lead pitch and radial terminal type, suitable for robust industrial and electronic circuit designs.
The capacitor case is made from flame retardant non-combustible epoxy resin, providing excellent protection and durability. Its built-in fuse and failsafe design prevent short circuits by opening upon failure, enhancing safety in critical applications.
Designed to endure vibration and environmental stress, the ECWFE series offers superior frequency characteristics and low loss with a low hum sound noise, making it ideal for high frequency and active filter circuits. It operates reliably across a wide temperature range from -40°C to 105°C.
Mechanical dimensions include a height of 12.5 mm, length of 17.5 mm, width of 7 mm, lead diameter of 0.6 mm, and a lead length of 20 mm, making it compact and versatile for various circuit board layouts.
Compliance with automotive standard AEC-Q200 and certifications UL 60384-14, EN 60384-14, and CSA E60384-14 ensure reliability in automotive and industrial sectors. This capacitor is encapsulated in self-extinguishing material meeting UL94V-0 standards for flame resistance.
Typical applications include use in power supplies, power factor correction circuits, servers, and diverse automation equipment where vibration resistance and electrical reliability are critical. Its polypropylene dielectric offers better performance compared to polyester alternatives.
Constructed with metallised polypropylene dielectric for superior electrical performance. Flame retardant epoxy resin enclosure ensures safety. Built-in fuse functionality for failsafe operation. High vibration resistance for industrial environments.
Wide operating temperature range (-40°C to 105°C). Compliant with automotive and international safety standards. Radial through hole mount with 15 mm lead pitch. Low dissipation factor of 0.1% for efficient performance.
Choose Panasonic ECWFE2J224J film capacitor for reliable, high-quality passive component requirements within electronics manufacturing, industrial automation, and automotive sectors. Explore related Panasonic Film Capacitors in the Electronics Components category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance value of this model is 220 nF with a tolerance of ±5%.
It can operate reliably at a maximum temperature of 105°C.
This capacitor features a radial through hole mount type.
The dimensions are 12.5 mm in height, 17.5 mm in length, and 7 mm in width.
It is rated for 630 V dc applications.
The lead pitch for this capacitor is 15 mm.
The capacitor is constructed with a metallised polypropylene dielectric and encased in a flame retardant epoxy resin.
Yes, it complies with the automotive standard AEC-Q200.
The dissipation factor is 0.1%, which indicates efficient performance.
The minimum operating temperature is -40°C.
It is suitable for use in power supplies, power factor correction circuits, servers, and various automation equipment.
It includes a built-in fuse functionality that ensures failsafe operation by opening the circuit on failure.
