Molex 4 Way Female PicoBlade to 4 Way Female PicoBlade Wire to Board Cable 100 mm 125V 15134-0401

Molex 15134-0401 is a wire to board cable assembly equipped with 4 Way Female PicoBlade connectors on both ends, designed for applications operating up to 125V. The assembly consists of a 100 mm long cable that supports reliable electrical connections where compact size and precision matter.

Featuring a 1.25 mm pitch between contacts, this cable facilitates efficient space utilization within tight electronic enclosures. The connector housings are manufactured from a thermoplastic material known for excellent impact resistance, ensuring connector durability and resistance to scratching or damage during handling and use.

The contact terminals are made from phosphor-bronze with tin plating that helps prevent corrosion and maintains conductivity over time, making this cable assembly dependable for long-term use in various environments.

The cable is constructed with UL1061 discrete wires bundled together, which reduces installation time by eliminating the need to handle wires individually. A friction lock on each connector ensures secure mating with corresponding PCB headers, preventing accidental disconnections caused by vibration or mishandling.

The 4-position, single-row PicoBlade connectors enable straightforward pin-to-pin mapping, aiding in prototyping and design simplicity. This assembly meets standards such as 2011/65/EU RoHS, ISO- and TS-16949, and UL1061.

Common applications include medical equipment such as patient monitors, mobile devices, and prototype circuitry requiring reliable small pitch connectors.

Manufactured in China, this cable assists engineers and OEMs in building compact and reliable electronic devices. Its versatile use spans industrial, medical, and consumer electronic sectors where wire-to-board connectivity is crucial.
