NVE Digital Non-Inverting Line Transceiver IC, 16-Pin SOIC, 3-5V Supply, 60mA Output IL3522E

The NVE IL3522E is a digital, non-inverting line transceiver IC designed for robust RS-485 communication bus applications. It is packaged in a surface-mount 16-pin SOIC configuration, offering an optimized footprint for modern electronic assemblies. Operating within a supply voltage range of 3 to 5 volts, it provides a maximum high-level output current of 60 milliamps to ensure reliable signal driving capability.

Featuring a maximum propagation delay of 35 nanoseconds at typical load capacitance, the IL3522E ensures efficient data transmission with minimal latency. Constructed using CMOS logic family technology, it supports digital input and output signals, maintaining data integrity with non-inverting polarity characteristics.

This line transceiver operates effectively over an extended temperature range from -40°C to 85°C, making it suitable for industrial, industrial automation, telecommunications, and other demanding environments requiring stable bus transceivers.

With compact physical dimensions measuring 10.49 mm in length, 7.42 mm in width, and 2.5 mm in height, the SOIC package enables easy integration into compact circuit designs. The device’s low supply current consumption of 6 milliamps aids in energy-efficient system designs.

Manufactured in the United States, the IL3522E meets quality standards expected for interface ICs used in line interface applications such as RS-485 line drivers and receivers with isolation features. It does not incorporate automotive standards or special approvals but remains a dependable choice for general electronic and industrial semiconductor applications.

Operates with a minimum supply voltage of 3 volts and maximum up to 5 volts. Provides a maximum high-level output current of 60 milliamps. Features a maximum propagation delay time of 35 nanoseconds at load capacitance. Compatible with digital input and output types and uses CMOS logic family.

Designed to operate reliably within temperature ranges from -40°C to 85°C. Compact dimensions with length 10.49 mm, width 7.42 mm, and height 2.5 mm. Consumes a supply current of 6 milliamps during operation. Ideal for RS-485 line driver and receiver applications with isolating capabilities.

Manufactured in the United States with quality and precision.
