NVE 2-Channel Digital Isolator 10 Mbps 2.5 kVrms Isolation 5.5V 8-Pin SOIC IL611A-3E

Free Delivery in India | Lowest Global Shipping Charges

NVE 2-Channel Digital Isolator 10 Mbps 2.5 kVrms Isolation 5.5V 8-Pin SOIC IL611A-3E



Category Digital Isolator ICs Brand NVE Condition New

Specifications

Country of Origin	United States
Brand	NVE
Length	5mm
Model	IL611A-3E
Depth	6.2mm
Width	1.75mm
Mount Type	Surface
Series	IL
Maximum Operating Temperature	85°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Maximum input current	75mA
Number Of Channels	2
Rise Time	10μs
Supply Voltage	5.5V
Standards/Approvals	UL, IEC
Maximum Forward Voltage	7V
Number of Pins	8
Maximum Data Rate	10Mbps
Propagation Delay Time	25ns
Package Style	SOIC

Key Features

The device features a maximum data rate of 10 Mbps ensuring fast digital signal isolation.
Provides high isolation voltage of 2.5 kVrms for enhanced circuit protection.
Compact 8-Pin SOIC package suitable for surface mounting.
Low propagation delay time of 25 ns supports high-speed applications.
Operates over a wide temperature range from -40°C to 85°C.
Utilizes patented IsoLoop spintronic GMR technology for superior performance.
Designed with a maximum forward voltage of 7 V enhancing efficiency.
Maximum input current rating is 75 mA for reliable operation.

Product Description

The NVE IL611A-3E is a 2-Channel Digital Isolator designed for high-performance digital signal isolation with a maximum data rate of 10 Mbps and isolation voltage rating of 2.5 kVrms. It is supplied at 5.5 V and comes in a compact 8-Pin SOIC package with surface mount capability.

This digital isolator leverages NVE's patented IsoLoop spintronic Giant Magnetoresistive (GMR) technology, enabling superior performance, lower power consumption, and higher package density compared to traditional opto-isolators. Its propagation delay time is a swift 25 ns, making it suited to applications requiring fast signal processing and reliable isolation.

With an operating temperature range from -40°C to 85°C, the IL611A-3E is suitable for demanding industrial, electronic, and communication applications where robust electrical isolation is critical. It features a maximum forward voltage of 7 V and can handle input currents up to 75 mA.

The device dimensions include a length of 5 mm, width of 1.75 mm, and depth of 6.2 mm, fitting comfortably in compact electronic assemblies. These specifications and its UL and IEC approvals ensure compliance with industrial safety standards.

Maximum data rate of 10 Mbps for rapid data transmission. High isolation voltage of 2.5 kVrms for superior circuit protection. Surface-mount 8-Pin SOIC package for space-saving PCB integration. Wide operating temperature range (-40°C to 85°C) for versatile industrial use.

Low propagation delay of 25 ns for efficient signal processing. Low power consumption with patented spintronic technology. Maximum forward voltage of 7 V ensuring operational efficiency. Maximum input current of 75 mA for reliability.

Compact physical dimensions aid electronic design.

This device is ideal for use in industrial automation, electronic instrumentation, telecommunications, and other applications requiring galvanic isolation of digital signals. Its robust performance characteristics and compliance with safety standards make it a reliable component for high-integrity electronic systems.
