NVE Digital Non-Inverting Line Transceiver, 16-Pin SOIC, Surface Mount, 7V Max Supply, 7mA Supply Current, IL3122E

Free Delivery in India | Lowest Global Shipping Charges

NVE Digital Non-Inverting Line Transceiver, 16-Pin SOIC, Surface Mount, 7V Max Supply, 7mA Supply Current, IL3122E



Category Line Interface IC Brand NVE Condition New

Specifications

Country of Origin	United States
Brand	NVE
Height	1.58mm
Length	9.5mm
Model	IL3122E
Width	7.29mm
Mount Type	Surface
Output type	Digital
Series	IL3122
Input Type	Differential
Maximum Operating Temperature	85°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Polarity	Non-Inverting
IC Type	Line Transceiver IC
Standards/Approvals	RoHS
Pin Count	16
Maximum Supply Voltage	7V
Logic Family	CML
Logic Function	Bus Transceiver
Minimum Supply Voltage	-0.5V
Maximum High Level Output Current	60mA
Maximum Propagation Delay Time @ CL	85ns
Supply Current	7mA

Key Features

Logic family is CML for robust performance.
Bus transceiver function supports RS-422 communication standards.
Operates with supply voltage from -0.5V to 7V.
Maximum propagation delay time is 85ns with a load capacitance.
Wide operating temperature range from -40°C to 85°C.
Compact physical dimensions of 9.5mm length, 7.29mm width, and 1.58mm height.
Maximum output current of 60mA for both high and low levels.
Consumption limited to 7mA supply current for energy efficiency.

Product Description

The NVE IL3122E is a digital, non-inverting line transceiver designed for reliable RS-422 line driver and receiver applications in industrial and communication systems. It features differential input signaling and digital output, which ensures noise immunity and signal integrity in harsh environments.

This component is housed in a 16-pin SOIC surface mount package, measuring 9.5mm in length, 7.29mm in width, and 1.58mm in height, suitable for compact PCB designs. Its operation covers a broad temperature range from -40°C to 85°C, making it ideal for automotive, industrial, and other rigorous applications.

The IL3122E supports supply voltages from -0.5V up to 7V with a low supply current of 7mA, enabling efficient power consumption in embedded systems. It provides maximum high and low output currents of 60mA, capable of driving various bus line loads effectively. The maximum propagation delay time under load capacitance conditions is 85ns, supporting high-speed data transmission requirements.

Conforming to RoHS directives, this transceiver ensures compliance with environmental and safety regulations. The device belongs to the IL3122 series and is manufactured in the United States, affirming quality and reliability standards.

Typical use cases include industrial communication networks, automation control systems, and embedded digital interfaces requiring robust line driver and receiver capabilities. Logic family: CML. Logic function: Bus transceiver.

IC type: Line transceiver IC. Input type: Differential. Output type: Digital. Polarity: Non-inverting. Mount type: Surface mount. Package type: SOIC. Pin count: 16. Operating temperature range: -40°C to 85°C. Explore more semiconductor interface ICs in the NVE product range on EnvMart for industrial and communication solutions.
