Texas Instruments 4-Channel CMOS Line Driver Interface IC, 3 State, 16-Pin SOIC, 4.5V-5.5V Supply DS26C31TMX/NOPB
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.75mm |
| Length | 10mm |
| Model | DS26C31TMX/NOPB |
| Width | 6.2mm |
| Mount Type | Surface |
| Output type | 3 State |
| Series | DS26C31T |
| Input Type | Differential |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| IC Type | Line Driver |
| Number Of Channels | 4 |
| Pin Count | 16 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | CMOS |
| Logic Function | Line Driver |
| Minimum Supply Voltage | 4.5V |
| Maximum Propagation Delay Time @ CL | 8ns |
| Supply Current | 500μA |
Key Features
- CMOS logic family technology for low power consumption.
- Line driver function with differential input and 3-state output.
- Surface mount SOIC package with 16 pins.
- Operating voltage between 4.5 and 5.5 volts.
- Maximum propagation delay of 8 ns at the specified load.
- Wide operating temperature range from -40°C to 85°C.
- Compact IC dimensions for PCB integration.
Product Description
Texas Instruments model DS26C31TMX/NOPB is a 4-channel line driver interface IC from the CMOS logic family. This device features a 3-state output and operates within a supply voltage range of 4.5 to 5.5 volts, making it suitable for various electronic and industrial applications.
The IC is designed to handle differential inputs with a 16-pin SOIC surface mount package that offers a compact footprint suitable for high-density circuit boards. Its maximum propagation delay time of 8 nanoseconds at the specified load capacitance guarantees efficient signal transmission and timing accuracy.
The operating temperature range from -40°C to 85°C ensures reliable performance in harsh environmental conditions. Measuring just 10 mm in length, 6.2 mm in width, and 1.75 mm in height, this interface IC fits well into compact and space-sensitive designs.
CMOS logic family technology for low power consumption. Line driver function with differential input and 3-state output. Surface mount SOIC package with 16 pins. Operating voltage between 4.5 and 5.5 volts. Maximum propagation delay of 8 ns at the specified load.
Wide operating temperature range from -40°C to 85°C. Compact IC dimensions for PCB integration.
This IC is ideal for applications in electronic components systems, industrial automation, instrumentation, and telecommunications where reliable line interface drivers are critical.
For more choices in Line Interface ICs and related semiconductor components, explore our extensive catalog at EnvMart to find the right match for your industrial and electronic project needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The supply voltage range for this model is between 4.5V and 5.5V.
The maximum propagation delay time at the specified load capacitance is 8 nanoseconds.
This IC measures 10 mm in length, 6.2 mm in width, and 1.75 mm in height.
It features 4 channels for line driving applications.
The operating temperature range is from -40°C to 85°C.
It accepts differential inputs.
The IC comes in a 16-pin SOIC surface mount package.
This model belongs to the CMOS logic family.
The output type is 3-state.
The supply current is 500μA.
It is suitable for applications in electronic components systems, industrial automation, instrumentation, and telecommunications.
The country of origin for this IC is India.
