Samtec SHF Series Straight Surface PCB Header, 16 Contacts, 1.27 mm Pitch, 2 Row, Shrouded SHF-108-01-L-D-SM

Samtec SHF-108-01-L-D-SM is a high-quality SHF Series Straight Surface PCB Header designed for precise electronic assembly requiring robust performance. It features 16 male contacts arranged in two rows with a standard 1.27 mm pitch, providing reliable electrical connections for complex circuit boards.

The connector housing is made of liquid crystal polymer, ensuring strong mechanical durability while supporting wide operating temperatures from -55°C to 125°C. Gold-plated phosphor bronze contacts guarantee excellent conductivity and corrosion resistance, essential for long-term reliability in industrial and HVAC electronics manufacturing environments.

The shrouded design includes a polarizing notch, preventing misalignment during mating operations. The connector uses a wire-to-board system with a straight orientation, optimized for surface mounting technology with solder termination for secure attachment on printed circuit boards.

This PCB header supports a maximum current of 3A, making it suitable for control panels, power supplies, and commercial electronic assemblies. Mating pin length is 3.05 mm, providing stable connectivity with compatible IDC socket cable assemblies such as the FFSD and FFTP series.

The product complies with environmental standards such as RoHS, ensuring it meets modern regulations for hazardous substances in electronics manufacturing. The housing made from Liquid Crystal Polymer offers mechanical strength and thermal stability.

Gold-plated contacts ensure reliable electrical performance and corrosion resistance. Double row with 16 contacts and 1.27 mm pitch matches industry-standard PCB layouts. Shrouded design with polarizing notch ensures correct connector mating.

Rated current of 3A supports moderate electrical loads. Operating temperature range from -55°C to 125°C adapts to diverse industrial conditions.

This Samtec SHF Series PCB Header is ideal for use in industrial, laboratory, manufacturing, HVAC control systems, and commercial electronic assemblies requiring compact and reliable PCB connections. Browse the Electronics Components category in EnvMart for compatible PCB connectors and headers.
