TDK Film Capacitor 12 nF 500V AC 1 kV DC Through Hole 2 Pin B32671L0123J000

TDK B32671L0123J000 film capacitor is a metallized polypropylene film capacitor designed for demanding electronic applications requiring high voltage and pulse tolerance.

This capacitor has a capacitance of 12 nF, rated for 500 V AC and 1 kV DC operation, making it ideal for high-frequency and resonant circuit applications. It features epoxy resin sealing for mechanical protection and long-term reliability.

The compact dimensions of 13 mm length, 12 mm height, and 6 mm width accommodate space-constrained PCB designs, and the 10 mm lead pitch with 0.6 mm diameter leads supports standard through-hole assembly methods.

Its peak voltage handling and high pulse withstand capability enable use in electronic ballasts, switched mode power supplies, pulse circuits, and other industrial and automotive electronics requiring robustness. The capacitor is compliant with automotive AEC-Q200 Rev D standards and carries UL and RoHS approvals, ensuring safety and environmental compliance.

This capacitor features metallized polypropylene film construction with epoxy resin sealing. It offers high peak voltage and current capabilities suitable for short duration pulses. Designed for operation up to 125° Celsius maximum temperature.

Typical applications include electronic ballasts, switched mode power supplies, and high-frequency AC loads. Through hole mount type with 10 mm lead pitch and 0.6 mm lead diameter. Complies with automotive standard AEC-Q200 Rev D as well as UL and RoHS certifications.

This component is suited to industrial, automotive, and manufacturing electronics assembly where durability and performance under electrical stress are critical. It provides reliable capacitance stability for resonant and filter circuits in commercial and industrial electronic systems.
