| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 1.1mm |
| Length | 2.7mm |
| Model | BZT52C2V7S-7-F |
| Mount Type | Surface |
| Series | BZT52C2V7S |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 200mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 20μA |
| Nominal Zener Voltage Vz | 2.7V |
| Zener Type | General Purpose |
| Maximum Zener Impedance | 100Ω |
| Typical Voltage Temperature Coefficient | -3.5mV/°C |
| Surface Mount case | SOD-323 (SC-76) |
DiodesZetex BZT52C2V7S-7-F is a single Zener diode optimized for voltage regulation and protection applications in electronic circuits. Featuring a nominal Zener voltage of 2.7 V, it is designed to operate with a maximum power dissipation of 200 milliwatts, making it well-suited for low-power semiconductor implementations.
The diode comes in a compact surface mount SOD-323 package, with precise dimensions of 2.7 mm length and 1.1 mm height, enabling space-efficient assembly on printed circuit boards. It features a 2-pin configuration, making integration simple and standardized.
Operational specifications include a voltage tolerance of ±7% and a test current of 5 mA to ensure stable voltage regulation. The maximum reverse leakage current of 20 μA reduces losses and improves efficiency in sensitive circuits. Additionally, the maximum Zener impedance is rated at 100 Ω.
Engineered to endure harsh environments, this diode supports an operating temperature range from -65°C up to 150°C, making it reliable for industrial, automotive, and commercial electronics applications. Its compliance with the AEC-Q101 automotive standard further confirms suitability for rigorous automotive system demands.
This general purpose Zener Diode is ideal for applications such as voltage clamping, reference voltage generation, and transient voltage suppression across industrial electronics, laboratory devices, and manufacturing systems.
The diode configuration is single element for precise control. The surface mount design facilitates automated production and compact device manufacturing. Its robust temperature range suits both low temperature and high temperature circuit conditions.
Voltage temperature coefficient is -3.5 mV/°C aiding in voltage stability under temperature fluctuations. Manufactured in China with adherence to quality and performance standards. Explore the full range of DiodesZetex semiconductor products on EnvMart for comprehensive electronic component sourcing.
