onsemi 2-Element Uni-Directional TVS Diode 150 W, 3-Pin SOT-323 DF3A6.8FUT1G

onsemi DF3A6.8FUT1G is a 2-element uni-directional TVS (Transient Voltage Suppressor) diode designed to provide high-level protection against voltage spikes in electronic circuits. Housed in a compact 3-pin SOT-323 surface mount package, this diode supports a peak pulse power dissipation of 150 watts and a clamping voltage of 16 V, ensuring efficient transient voltage suppression.

Its common anode diode configuration and uni-directional design make it suitable for protecting sensitive semiconductor devices from electrostatic discharge (ESD) and electrical surges. The device operates effectively across a wide temperature range from -55°C up to 150°C, enhancing reliability in various environmental conditions.

With a minimum breakdown voltage of 7.2 V and maximum reverse stand-off voltage of 5 V, the DF3A6.8FUT1G offers precise voltage clamping and suppression capabilities. The maximum peak pulse current rating of 9.37 A ensures it can absorb substantial surge currents without damage. Additionally, its low leakage current of 500 nA contributes to energy efficiency and reduced power loss.

The diode incorporates two elements per chip, providing dual protection elements within a single package. This feature improves surge protection effectiveness in demanding industrial, automotive, and consumer electronic applications.

This model has no specific international certifications or automotive standards compliance but is engineered for reliable transient suppression in semiconductor and power electronics circuits.

Offers transient voltage suppression with a peak pulse power dissipation of 150 watts. Uni-directional diode configuration with a common anode and 3 pins. Clamping voltage is 16 volts with a minimum breakdown voltage of 7.2 volts.

Designed for surface mount applications with SOT-323 package type. Operates reliably from -55°C to 150°C ambient temperature range. Maximum peak pulse current of 9.37 amperes ensures effective surge protection. Low maximum reverse leakage current of 500 nA for enhanced efficiency.

Includes 2 elements per chip for robust transient suppression. ESD protection capability included to safeguard sensitive electronics. Compact dimensions: 2.2 mm length, 1.35 mm width, and 0.9 mm height.

This product is ideal for use in industrial electronics, power supply circuits, automotive electronics, and other applications requiring robust transient voltage protection. Suitable for manufacturing and repair operations that demand compact, efficient ESD protection components.
