Keithley 2600 Series Source Meter, 2-Channel, ±200 mV to ±200 V, ±100 nA to ±10 A, 60W Output 2612B

Keithley 2612B Source Meter from the 2600 Series integrates advanced Source Measurement Unit (SMU) technology with dual-channel capabilities, providing precise control and measurement of current and voltage.

This instrument supports a source voltage range from ±200 mV to ±200 V and a source current range from ±100 nA to ±10 A, with an output power capacity of 60 watts. It delivers 6½ digit resolution measurements, making it suitable for highly sensitive electrical and electronic component testing.

The 2612B features built-in Java-based test software, enabling plug and play I/V characterization accessible from any browser globally. Its Test Script Processing (TSP) technology allows embedding full test programs directly into the device for exceptional system throughput and efficiency.

Connectivity options include USB 2.0, LXI-C, GPIB, RS-232, and digital I/O, allowing integration into various automated test systems. The model measures resistance across a wide spectrum from 500 nΩ up to 100 TΩ, supporting a broad range of testing applications.

Applications range from semiconductor wafer and thin film testing, nanomaterials characterization such as graphene and carbon nanotubes, discrete and passive component analysis including resistors and diodes, to organic materials and device evaluation such as printable electronics. It is widely used in R&D laboratories, production testing environments, education, and quality assurance settings.

The instrument meets international compliance standards including EN 61326-1, UL, and 89/336/EEC, ensuring safety and electromagnetic compatibility in industrial and laboratory use.

The package includes operator and programming manuals, a low noise Triax cable with alligator clips, mating screw terminal connectors with strain relief and covers, TSP-Link/Ethernet cables (two per unit), embedded TSP Express software, Test Script Builder software on CD, and a LabVIEW driver for versatile development support.

Offers 2 channels for simultaneous current and voltage operations. Voltage range spans from ±200 mV to ±200 V for versatile applications. Current range extends from ±100 nA to ±10 A, supporting sensitive measurements. Provides a maximum output power of 60 watts for robust performance.

Built-in Java-based test software enables plug and play I/V characterization remotely. Includes Test Script Processing technology for embedded, optimized test programs. Interfaces include USB 2.0, LXI-C, GPIB, RS-232 and digital I/O for flexible connectivity.

Ideal for R&D, production testing, education, and quality assurance. Measures resistance in the range 500 nΩ to 100 TΩ with high precision. Complies with EN 61326-1, UL, and 89/336/EEC standards. Explore the Keithley range and other advanced test measurement instruments to enhance your laboratory or production capabilities on EnvMart.
