Keithley Digital Bench Power Supply 5-Output 0 V to 30 V 720 W 72 A Max 2260B-30-72
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | Keithley |
| Power | 720W |
| Height | 124mm |
| Model | 2260B-30-72 |
| Depth | 350mm |
| Width | 71mm |
| Output type | Digital |
| Maximum Operating Temperature | 50°C |
| Minimum Operating Temperature | 0°C |
| Plug Type | IEC 320 |
| Interfaces | USB, LAN, or an optional GPIB Interface for automated control |
| Number of outputs | 5 |
| Maximum Output Current | 72A |
| Standards/Approvals | RoHS |
| Maximum Output Voltage | 30V |
| Maximum Supply Voltage | 265V ac |
| Digital/Analogue | Digital |
| Supported Number of Displays | 1 |
| Minimum Output Voltage | 0V |
| Minimum Output Current | 0A |
| Save bench and test system space | six 71mm wide 360 W units or three 142 mm wide 720 W units or two 214 mm wide 1080 W units fit in a standard rack width |
Key Features
- The device features digital control with a single display for convenient operation.
- It supports multiple interfaces including USB, LAN, and optional GPIB for automated control.
- The power supply has a broad operating temperature range from 0°C to 50°C.
- Compact design allows integration in standard rack widths, saving bench and test system space.
- Advanced features include constant current priority and programmable output resistance.
- Ideal for environmental, stress, life testing and battery research applications.
- Protects connected equipment by preventing damage from inrush current to low impedance loads.
Product Description
Keithley 2260B-30-72 digital bench power supply is a high-performance programmable device designed to provide constant power output with flexible voltage and current combinations. It supports 5 outputs ranging from 0 V to 30 V, delivering up to 720 W of power and a maximum output current of 72 A. This instrument includes advanced features such as constant current priority, programmable output resistance, and programmable voltage/current rise and fall times to protect low impedance loads from inrush current, making it suitable for a wide range of industrial and laboratory applications.
The compact form factor with dimensions (124 mm height, 71 mm width, and 350 mm depth) allows multiple units to be installed in standard rack widths, optimizing bench space. The power supply supports digital control with a single display and offers various interfaces including USB, LAN, and an optional GPIB interface for automated test systems. Its operational temperature range is from 0°C to 50°C, ensuring reliable performance across different environments.
Typical applications include environmental testing, stress tests, accelerated life testing, LED and high power component testing, automotive testing, battery research and production testing. The capability to combine multiple units in series or parallel via Master-slave configuration further extends its voltage and current output ranges. Additionally, the unit complies with RoHS standards and is sourced from Taiwan, Province Of China.
The power supply is programmable with digital output and multiple interfaces for flexible control. Features protections such as inrush current damage prevention and constant current priority setting. Compact and space-saving design supports installation in rack systems.
High power density with 720 W output power and 72 A maximum current facilitates demanding applications. Wide operating temperature range from 0°C to 50°C for versatile usage conditions. Supports automated control through USB, LAN, and optional GPIB interfaces.
Enables flexible voltage and current output combinations suitable for research and testing environments.
This Keithley bench power supply model 2260B-30-72 is backed by a three-year warranty and supported by KickStart software for enhanced control and operation. It is a reliable and efficient power source for industrial, laboratory, manufacturing, and testing applications. Browse similar Keithley power supplies and related measuring instruments on EnvMart for comprehensive solutions.
