Keithley Digital Bench Power Supply, 1-Output, 0 V AC to 80 V, 360 W, 13.5 A Max 2260B-80-13

Keithley 2260B-80-13 digital bench power supply provides a reliable single output ranging from 0 V AC to 80 V AC with a maximum power rating of 360 W and maximum output current of 13.5 A. This high-precision power supply is designed for diverse industrial and laboratory applications including environmental tests, automotive testing, LED and high power component testing, and battery research.

The unit features a compact 71 mm wide chassis and a height of 124 mm, allowing six units to fit in a standard rack, saving valuable bench space. It supports advanced programmable control such as voltage and current rise and fall times, which prevents damage from inrush current especially when powering low impedance loads or LEDs.

Multiple interfaces including USB, LAN, and an optional GPIB interface provide versatile options for automated test systems. The power supply includes a unique feature to simulate battery output via programmable output resistance and supports master-slave configurations to combine outputs for higher voltage or current capabilities.

Designed to operate within 0°C to 50°C ambient temperature, the device complies with RoHS standards and uses IEC 320 plug type ensuring safety and compatibility. Its digital output supports precise voltage and current monitoring and control.

This Keithley power supply series offers three power options - 360 W, 720 W, and 1080 W - with voltage outputs up to 800 V and current ratings up to 108 A, providing scalable solutions to meet demanding power testing needs.

High power density with a compact form factor of 71mm width. Programmable output voltage and current for precise testing. Multiple control interfaces including USB, LAN, and optional GPIB. Advanced features like programmable output resistance and constant current priority setting.

Suitable for environmental, stress, accelerated life, and automotive testing applications. Supports master-slave configuration for increased voltage or current. RoHS compliant and built to operate from 0°C to 50°C ambient temperature.

Standard 360 W model enabling bench space saving in racks. Designed with IEC 320 plug type and digital output control. Country of origin: Taiwan, Province Of China.

This digital Bench Power Supply is ideal for industries such as manufacturing testing, research laboratories, automotive component testing, and electronics stress and life cycle testing. Its precision and programmability make it suitable for complex applications requiring reliable, accurate DC power sources. Browse more power supplies and measurement instruments at EnvMart for professional-grade equipment.
