Keithley Digital Bench Power Supply 1 Output 0 to 800 V, 720 W, 2.88 A Max 2260B-800-2

Keithley 2260B-800-2 is a programmable digital bench power supply delivering a single output voltage ranging from 0 V to 800 V with a maximum power of 720 W and current capability up to 2.88 A. This high-quality instrument supports flexible power configurations ideal for laboratory, industrial, and manufacturing applications.

This model provides constant power output that can be programmed with precise voltage and current limits. It features programmable voltage or current rise and fall times, which prevent damage from inrush currents to sensitive low-impedance loads. The constant current priority setting reduces voltage and current overshoot, particularly useful when powering LEDs.

The 2260B-800-2 can simulate a battery's output with programmable output resistance, making it suitable for battery research and automotive test setups. Its digital output and communication interfaces include USB, LAN, and optional GPIB, enabling automated control and seamless integration into test systems.

The compact form factor enables efficient bench use: six 71 mm wide 360 W units or three 142 mm wide 720 W units fit in a standard rack width. Its operating temperature range of 0°C to 50°C makes it reliable in diverse testing environments.

Typical applications encompass environmental testing, accelerated life testing, high power component testing, automotive applications, battery testing, and production test setups. The product is RoHS compliant, ensuring environmental safety standards.

Single output with flexible programmable DC voltage and current ranges. 720 W power capacity with 2.88 A maximum current. Multiple control interfaces including USB, LAN, and optional GPIB. Designed for precision testing in laboratory, manufacturing, and automotive sectors.

Compact design fits multiple units in test racks to save bench space. Programmable output resistance to simulate battery characteristics. Protection against inrush current damage with programmable rise/fall time. RoHS compliant for environmental compliance assurance.

The Keithley 2260B-800-2 digital Bench Power Supply is engineered for precise and versatile power delivery in industrial, laboratory, and manufacturing testing environments. Explore other bench power supplies and measurement instruments at EnvMart to suit all your technical requirements.
