Keithley 2600 Series Source Meter, ±200 mV to 200 V, 2-Channel, ±100 pA to 1.5 A, 60W Output 2636B

Keithley 2636B 2600 Series Source Meter is a precision dual-use instrument combining voltage/current sourcing and measurement capabilities with 6½ digit resolution, tailored for rigorous electrical testing across multiple industries.

Operating within a voltage range of ±200 mV to 200 V and a current range of ±100 pA to 1.5 A, this 2-channel source meter integrates a 60W output power supply, enabling detailed component characterization and parameter extraction.

Built on Keithley's third generation SMU (Source Measure Unit) technology, it encompasses features such as a true current source, precision resistance and voltage measurement, arbitrary waveform and pulse generation, and electronic load functionalities within one compact system.

The instrument's embedded Java-based test software facilitates seamless I/V characterization from any computer browser worldwide, eliminating the need for additional setup and promoting test efficiency and flexibility.

Its Test Script Processing (TSP) technology allows the embedding of complete test programs providing superior system-level throughput. The TSP-Link expansion supports multi-channel parallel testing without requiring a mainframe, enhancing scalability for complex measurement setups.

Connectivity is versatile, with USB 2.0, LXI-C, GPIB, RS-232, and digital I/O interfaces standard, ensuring compatibility with various test environments and automated test systems.

Typical applications include semiconductor wafer and thin film testing, evaluation of nanomaterials such as graphene and carbon nanotubes, assessment of discrete and passive components like resistors and diodes, organic material characterization, and material resistivity or Hall effect measurement.

The product is supplied with operator and programming manuals, two low noise 2-meter Triax cables with alligator clips, TSP-Link/Ethernet cables (two per unit), TSP Express embedded software, Test Script Builder software on CD, and comprehensive LabVIEW drivers improving integration and programming capabilities.

Originating from China, the Keithley 2600 Series 2636B model upholds industry standards including EN 613261, UL, and 89/336/EEC approvals, catering to industrial, laboratory, research, and quality assurance needs.

Explore the full range of Keithley Source Meters at EnvMart for advanced electrical measurement solutions that enhance accuracy and productivity in your testing processes. Provides dual-use functions as a voltage/current source and measurement instrument with 6½ digit resolution.

Operates with ±200 mV to 200 V voltage range and ±100 pA to 1.5 A current range. Features built-in Java-based test software enabling plug & play I/V characterization through any browser. Includes advanced Test Script Processing (TSP) technology for embedded test programs and high throughput.

Offers multiple interface options including USB 2.0, LXI-C, GPIB, RS-232, and digital I/O for flexible connectivity. Supports multi-channel parallel testing via TSP-Link expansion technology without a mainframe. Designed for semiconductor, nanomaterial, and component testing in research, production, and quality assurance applications.

Includes operator manuals, low noise Triax cables, TSP-Link/Ethernet cables, TSP Express and Test Script Builder software, and LabVIEW drivers.
