Wurth Elektronik 0.5 mm Pitch 8 Way Straight Male FPC Connector, Solder Pin 68710814022

Wurth Elektronik 68710814022 is a high-quality 0.5 mm pitch 8 way straight male FPC Connector designed for wire-to-board applications with solder pin termination. This surface mount, top contact connector provides a robust solution for compact electronic assemblies requiring reliable and low insertion force connections.

Manufactured with phosphor bronze contacts plated with tin over nickel and housed in liquid crystal polymer, this connector ensures durability and flame retardance according to UL94-V0 standards. It supports a current rating of 500 mA and a voltage rating of 50 V, making it suitable for low-voltage signal transmission in various industrial and commercial electronics.

The series 687 connector is engineered for up to 25 mating cycles with a Zero Insertion Force mechanism to prevent damage during assembly and maintenance. Its straight orientation and single row of 8 contacts provide a compact footprint, ideal for space-constrained designs.

This connector operates reliably in a temperature range from -25°C to 85°C, making it suitable for environments with moderate temperature fluctuations typically found in electronics manufacturing and assembly. The locking mechanism ensures secure connections to prevent accidental disconnects.

Applications include PCB interconnections in industrial equipment, electronic devices, and specialized manufacturing setups where precise pin contacts and efficient mounting are critical. It supports seamless integration with FPC and jumper cables designed for this pitch and series.

The connector has 8 contacts with a 0.5 mm pitch suitable for compact designs. It supports a current rating of up to 500 mA and a voltage rating of 50 V. Contact material is phosphor bronze with tin over nickel plating ensuring reliability.

The housing is made of liquid crystal polymer providing UL94-V0 flame rating. Operating temperature range spans from -25°C to 85°C. The connector features a locking mechanism and a single row of contacts with straight orientation.

Designed for 25 mating cycles with low insertion force. Ideal for electronic, industrial, and manufacturing applications requiring reliable board connections. Explore more electronic connectors and components from Wurth Elektronik and enhance your industrial and manufacturing projects with trusted quality from EnvMart.
