Wurth Elektronik Wirewound Surface Mount Inductor 330 μH ±20% 1.1 A Idc Ferrite Core 1280 Package WE-PD 744770233
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 8mm |
| Brand | Wurth Elektronik |
| Height | 8mm |
| Length | 12mm |
| Depth | 12mm |
| Packaging | Tape & Reel |
| Series | WE-PD |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 330μH |
| Standards/Approvals | RoHS, REACH |
| Package/Case | 1280 |
| Maximum DC Current | 1.1A |
| Pin Count | 2 |
| Maximum DC Resistance | 640mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 3MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
| Recommended solder profile | Reflow |
Key Features
- Inductance value is 330 μH with ±20% tolerance.
- Supports maximum DC current of 1.1 A for efficient energy handling.
- Compact 1280 package with 12 mm length and 8 mm height for surface mounting.
- Magnetically shielded design minimizes leakage fields and interference.
- Rated for operating temperatures from -40°C to 125°C for durability.
- Complies with RoHS and REACH standards ensuring environmental safety.
- Constructed with ferrite core for low self-losses and high current capacity.
- Suitable for high-efficiency switching regulators and integrated DC/DC converters.
Product Description
Wurth Elektronik 744770233 is a wirewound Surface Mount Inductor featuring a ferrite core, designed for advanced electronic components applications. This inductor has an inductance of 330 μH with a tolerance of ±20% and supports a maximum DC current of 1.1 A, making it suitable for power and signal conditioning circuits.
The component comes in a 1280 tape and reel packaging style with dimensions of 12 mm length, 8 mm height, and 8 mm diameter. Its magnetically shielded construction results in a low leakage field, optimizing electromagnetic interference performance, crucial for sensitive electronics.
Rated for operating temperatures between -40°C and 125°C, this inductor complies with automotive standard AEC-Q200, RoHS, and REACH directives, ensuring reliability and environmental compliance.
Its wirewound construction on a ferrite core offers high current capacity with low self losses, making it ideal for switching regulators operating at low voltages and high efficiencies (>86%), DC/DC conversion circuits, and graphic card power supplies.
Inductance value is 330 μH with ±20% tolerance. Maximum DC current rating of 1.1 A supports demanding power loads. Compact 1280 package designed for surface mount technology. Magnetically shielded housing reduces electromagnetic interference.
Robust operating temperature range from -40°C to 125°C. Environmental compliance with RoHS and REACH standards. Ferrite core wirewound construction for optimal performance. Suitable for switching regulators and integrated DC/DC converters.
Recommended reflow soldering for reliable electrical connection. This inductor is perfect for industrial and electronic applications including power supply units, automotive electronics, and high-efficiency switching power regulators.
Explore our Electronics Components category for more premium inductors and surface mount solutions at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this inductor is 330 μH with a tolerance of ±20%.
It supports a maximum DC current of 1.1 A, making it suitable for demanding power loads.
The dimensions of the 1280 package are 12 mm in length, 8 mm in height, and 8 mm in diameter.
This inductor is rated for operating temperatures from -40°C to 125°C.
It is constructed with a ferrite core, which provides low self-losses and high current capacity.
It complies with RoHS and REACH standards, ensuring environmental safety.
The recommended solder profile for this inductor is reflow soldering for reliable electrical connection.
This inductor features a wirewound construction, which enhances its performance in various applications.
It is suitable for high-efficiency switching regulators, integrated DC/DC converters, and power supply units.
The maximum self-resonant frequency is 3 MHz, which is important for its performance in high-frequency applications.
This model has a pin count of 2, suitable for surface mounting.
It meets the automotive standard AEC-Q200, ensuring its reliability for automotive applications.
