Wurth Elektronik 2.2 μH Shielded Wirewound Surface Mount Inductor 1.3 A Idc Ferrite Core WE-TPC 744028002
Specifications
| Country of Origin | India |
|---|---|
| Brand | Wurth Elektronik |
| Operating Temperature | - 40 to +125°C |
| Height | 1.1mm |
| Length | 2.8mm |
| Depth | 2.8mm |
| Packaging | Tape & Reel |
| Series | WE-TPC |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 2.2μH |
| Package/Case | 2811 |
| Maximum DC Current | 1.3A |
| Pin Count | 2 |
| Maximum DC Resistance | 155mΩ |
| Inductance Tolerance | ±30 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100MHz |
| Inductor Construction | Wirewound |
| RoHS, REACH, JEDEC JS709B, IPC/JEDEC J-STD-020E, IEC 61249-2-21, IEC 60286-3 | 2013 |
Key Features
- The inductor features a ferrite core material for enhanced magnetic properties.
- Constructed as a wirewound inductor with magnetically shielded design to minimize leakage fields.
- Compact 2811 package with dimensions 2.8 mm length, 2.8 mm depth, and 1.1 mm height.
- Suitable for high temperature operation from -40°C to 125°C.
- Surface mount termination style simplifies PCB assembly and integration.
- Certified with RoHS, REACH, JEDEC JS709B, IPC/JEDEC J-STD-020E, and IEC standards ensuring quality and compliance.
- Maximum DC resistance of 155 mΩ ensuring efficient current conduction.
- Ideal for portable power applications including PDAs, digital cameras, PCMCIA cards, and embedded PCs.
Product Description
Wurth Elektronik 744028002 is a 2.2 μH shielded wirewound Surface Mount Inductor with a ferrite core designed for compact high-current applications. This component supports a maximum DC current of 1.3 A and offers ±30 % inductance tolerance, making it suitable for various electronic power applications.
The product uses the WE-TPC series 2811 package, measuring 2.8 mm in length and depth, with a height of 1.1 mm. Its magnetically shielded wirewound construction reduces leakage fields, ensuring reliable performance in sensitive electronic environments.
Operating temperature range extends from -40°C to +125°C, accommodating a wide range of environmental conditions. It features surface mount termination for easy PCB mounting and automated assembly, supplied in tape and reel packaging.
The inductor complies with industry standards including RoHS, REACH, JEDEC JS709B, IPC/JEDEC J-STD-020E, IEC 61249-2-21, and IEC 60286-3:2013, assuring compliance and quality.
Typical applications include portable power devices like PDAs, digital cameras, PCMCIA cards, embedded PCs, mobile data gathering, telemetric devices, and DC/DC converters where low leakage and high current handling are critical.
The inductor features a ferrite core for optimal magnetic performance. Compact 2.8 mm x 2.8 mm footprint and low profile of 1.1 mm height. Wirewound and magnetically shielded construction for low leakage field. Surface mount termination style enables automated PCB assembly.
Maximum DC current rating of 1.3 A and resistance of 155 mΩ support efficient operation. Wide operating temperature range from -40°C to 125°C. Compliance with multiple international safety and environmental standards. Packaging in tape and reel format for manufacturing efficiency.
This Wurth Elektronik inductor is ideal for industrial and commercial electronics manufacturing and design, particularly in portable and embedded power solutions. Discover more quality inductors and electronic components in related categories at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 2.2 μH with an inductance tolerance of ±30%.
It supports a maximum DC current of 1.3 A, allowing for efficient operation in high-current applications.
This unit has a compact size with dimensions of 2.8 mm in length, 2.8 mm in depth, and a height of 1.1 mm.
The inductor operates within a temperature range of -40°C to +125°C, making it suitable for various environmental conditions.
It features a ferrite core material, which enhances its magnetic properties and performance.
This model utilizes a surface mount termination style, simplifying PCB assembly and integration.
It is supplied in tape and reel packaging, which is designed for efficient manufacturing processes.
It complies with several standards including RoHS, REACH, JEDEC JS709B, IPC/JEDEC J-STD-020E, and IEC standards, ensuring quality and compliance.
The maximum DC resistance is 155 mΩ, which supports efficient current conduction.
Typical applications include portable power devices such as PDAs, digital cameras, PCMCIA cards, and embedded PCs.
The maximum self-resonant frequency for this model is 100 MHz, allowing it to perform effectively in high-frequency applications.
It is constructed as a wirewound inductor with a magnetically shielded design to minimize leakage fields.
