Vishay Zener Diode 16 V Nominal, 500 mW Surface Mount 2-Pin SOD-80 TZMC16-GS08

Free Delivery in India | Lowest Global Shipping Charges

Vishay Zener Diode 16 V Nominal, 500 mW Surface Mount 2-Pin SOD-80 TZMC16-GS08

Name: Vishay Zener Diode 16 V Nominal, 500 mW Surface Mount 2-Pin SOD-80 TZMC16-GS08
Brand: Vishay
SKU: 127790
Price: 0.05 USD
Availability: InStock



Category Zener Diodes Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Length	3.7mm
Model	TZMC16-GS08
Mount Type	Surface
Series	TZM
Maximum Operating Temperature	175°C
Package Type	SOD-80
Minimum Operating Temperature	-65°C
Standards/Approvals	RoHS
Pin Count	2
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	100nA
Nominal Zener Voltage Vz	16V
Zener Type	Voltage Regulator
Maximum Zener Impedance	40Ω

Key Features

This device operates as a single-element Zener diode with 5% voltage tolerance.
It supports a maximum power dissipation of 500 mW for reliable operation.
Package type is SOD-80, designed for surface mounting applications.
Maximum operating temperature is 175 degrees Celsius, ensuring thermal stability.
Typical test current for voltage regulation is 5 mA.
It exhibits a maximum reverse leakage current of 100 nanoamperes for low leakage losses.
The maximum Zener impedance is rated at 40 ohms promoting stable voltage regulation.
Certified with RoHS compliance and automotive standard AEC-Q101 qualification.

Product Description

Vishay TZMC16-GS08 is a surface mount Zener diode designed for voltage regulation with a nominal Zener voltage of 16 volts and power dissipation capability of 500 mW. It features a 2-pin SOD-80 package allowing compact PCB mounting, suitable for electronic, semiconductor, and power management applications.

The single-element construction ensures precise voltage control within a 5% tolerance. This diode operates reliably from low temperatures of -65 degrees Celsius up to a maximum of 175 degrees Celsius, making it appropriate for varied industrial conditions, including automotive systems requiring AEC-Q101 certification.

The device has a test current of 5 mA and a maximum reverse leakage of 100 nanoamperes, supporting efficiency in circuit designs by minimizing leakage current losses. Its maximum Zener impedance of 40 ohms ensures minimal voltage fluctuation during operation.

With its RoHS certification, it meets environmental safety standards for lead-free and hazardous substance compliance. The compact 3.7 mm length provides flexibility in high density circuit board layouts.

This Zener diode operates as a voltage regulator element for precision electronic circuits. Approved for automotive applications with AEC-Q101 standard compliance. Ideal for industrial, automotive, telecommunications, and electronic equipment manufacturing.

Surface mount footprint supports automated assembly processes improving production efficiency. Low leakage current and stable impedance enable consistent performance under varying electrical conditions.

Choose Vishay TZMC16-GS08 for reliable high-performance voltage regulation in demanding electronic system designs. Explore a wide range of semiconductor components and industrial electronics at EnvMart.
