Preci-Dip 32 Way 2.54 mm Pitch Vertical Surface Mount Turned Pin Open Frame DIL Socket 1A 110-87-632-41-105161

Preci-Dip 110-87-632-41-105161 is a 32 Way Dual In-Line (DIL) Socket with a 2.54 mm pitch, vertical orientation, and surface mount design for electronic components requiring precise connection and easy circuit testing.

Constructed with an open frame to allow easy access and insertion of ICs, this socket is engineered for durability and high reliability in industrial and laboratory electronic applications.

The contacts are made of beryllium copper alloy and brass with tin and gold plating to ensure optimum electrical conductivity and corrosion resistance. Its fibreglass reinforced polyethylene terephthalate housing provides mechanical robustness and stability during soldering and operational use.

Rated for 1 Ampere current and 150V DC voltage, it supports a broad range of medium power electronic circuits. The device operates efficiently across a wide temperature range from -55°C up to 125°C, making it suitable for harsh industrial environments.

This socket is compatible with reflow soldering techniques, including vapor phase soldering, facilitated by gull wing termination pins which offer strong mechanical and electrical bonds with printed circuit boards.

Dimensions include a length of 40.6 mm, width of 17.7 mm, and a depth of 2.8 mm, maximizing PCB layout efficiency while maintaining reliable connector performance. Manufactured in Switzerland, it complies with high-quality manufacturing standards without formal approvals.

The socket contains 32 contacts with a 2.54 mm pitch ensuring compatibility with standard IC packages. It is designed for surface mounting with vertical orientation facilitating compact PCB designs. Open frame construction enhances circuit testing and maintenance access.

Materials include beryllium copper alloy and brass for contacts with tin and gold plating. Operating temperature range supports industrial and laboratory use environments. Compatible with modern reflow soldering processes including vapour phase soldering.

Compact and precise physical dimensions optimize PCB footprint.

This Preci-Dip DIL Socket is ideal for industrial electronics manufacturing, assembly, repair, and laboratory testing applications. Browse the full range of DIL Sockets on EnvMart for compatible components and accessories.
