Wurth Elektronik WE-PD2 Unshielded Wirewound Surface Mount Inductor with Ferrite Core 470 μH ±10% 360 mA DC Current 744775247
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Height | 5mm |
| Length | 7.8mm |
| Depth | 7mm |
| Packaging | Tape & Reel |
| Series | WE-PD2 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 470μH |
| Standards/Approvals | RoHS |
| Maximum DC Current | 360mA |
| Maximum DC Resistance | 1.96Ω |
| Inductance Tolerance | ±10 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 3MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with a ferrite core ensuring stable magnetic properties.
- Compact dimensions with 7.8 mm length, 7 mm depth, and 5 mm height.
- Maximum DC resistance of 1.96 Ω for efficient performance.
- Packaged in Tape & Reel suitable for automated assembly.
- Complies with RoHS and automotive standard AEC-Q200.
- Operates reliably in temperatures ranging from -40°C to 125°C.
- Maximum self-resonant frequency of 3 MHz for versatile electronic applications.
- Designed as wirewound inductor suitable for surface mount technology.
Product Description
Wurth Elektronik 744775247 WE-PD2 unshielded wirewound surface mount inductor with ferrite core, featuring an inductance of 470 μH ±10% and rated for a maximum DC current of 360 mA. This inductor is constructed with a ferrite core, offering excellent magnetic characteristics ideal for power management applications.
Measuring 7.8 mm in length, 7 mm in depth, and 5 mm in height, this compact component fits efficiently in space-constrained PCB designs. It has a maximum DC resistance of 1.96 Ω, ensuring good current flow with minimal losses.
Packaged on tape & reel, it supports automated placement processes enhancing manufacturing efficiency. The component meets RoHS compliance and adheres to the automotive standard AEC-Q200, guaranteeing quality and reliability in automotive and industrial environments.
Engineered to withstand operating temperatures from -40°C to 125°C, the inductor maintains stable performance in harsh conditions. Its maximum self-resonant frequency of 3 MHz makes it suitable for filtering and energy storage in switching regulators and integrated DC/DC converters.
This wirewound, unshielded surface mount inductor is ideal for use in automotive electronics, industrial power supplies, and consumer electronic devices requiring efficient inductive components.
Constructed with a ferrite core ensuring stable magnetic properties. Compact dimensions with 7.8 mm length, 7 mm depth, and 5 mm height. Maximum DC resistance of 1.96 Ω for efficient performance. Packaged in Tape & Reel suitable for automated assembly.
Complies with RoHS and automotive standard AEC-Q200. Operates reliably in temperatures ranging from -40°C to 125°C. Maximum self-resonant frequency of 3 MHz for versatile electronic applications. Designed as wirewound inductor suitable for surface mount technology.
Explore more electronic components like Surface Mount Inductors and passive components on EnvMart for your industrial and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this inductor is 470 μH ±10%.
It has a maximum DC current rating of 360 mA.
The dimensions are 7.8 mm in length, 7 mm in depth, and 5 mm in height.
The maximum DC resistance is 1.96 Ω.
The maximum self-resonant frequency is 3 MHz.
It operates reliably in temperatures ranging from -40°C to 125°C.
Yes, it complies with RoHS and the automotive standard AEC-Q200.
The inductor is constructed with a ferrite core.
It is packaged in Tape & Reel, making it suitable for automated assembly processes.
The termination style of this inductor is surface mount.
This model is suitable for applications in automotive electronics, industrial power supplies, and consumer electronic devices.
It belongs to the WE-PD2 series.
