KEMET C4C Film Capacitor, 22 nF, ±5 %, 3 kV DC, 750 V AC, Through Hole Mount C4CAYUC2220AA0J
Specifications
| Country of Origin | India |
|---|---|
| Brand | KEMET |
| Height | 17mm |
| Length | 33mm |
| Model | C4CAYUC2220AA0J |
| Packaging | Bag |
| Width | 17mm |
| Mount Type | Through Hole |
| Series | C4C |
| Maximum Operating Temperature | 85°C |
| Tolerance | ±5 % |
| Capacitance | 22nF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Wire |
| Dissipation Factor | 0.0005% |
| Lead Length | 6mm |
| Standards/Approvals | EN 61071, IEC 61071, VDE 0560 |
| Package/Case | Plastic |
| Pin Count | 2 |
| Rated AC Voltage | 750V ac |
| Rated DC Voltage | 3kV dc |
| Lead Diameter | 1mm |
| Equivalent Series Resistance ESR | 42mΩ |
Key Features
- Rated for 3 kV DC and 750 V AC voltage for robust performance.
- Through hole mount type for secure PCB installation.
- Plastic package case with 17 mm height, width, and 33 mm length dimensions.
- Low dissipation factor of 0.0005% ensuring high efficiency.
- Equipped with 6 mm lead length and 1 mm lead diameter wire terminals for easy soldering.
- Operating temperature range from -40°C to +85°C suitable for diverse environments.
- Conforms to standards EN 61071, IEC 61071, and VDE 0560 for quality assurance.
- Designed as metallised polypropylene snubber capacitor ideal for voltage peak suppression in electronic and motor circuits.
Product Description
KEMET C4CAYUC2220AA0J Film Capacitor is a high-quality polypropylene film capacitor with a capacitance of 22 nF and a tolerance of ±5%. It is designed to operate at a rated DC voltage of 3 kV and AC voltage of 750 V, making it suitable for high voltage applications requiring reliable and stable performance.
This capacitor features a through hole mount type and is housed in a durable plastic package case measuring 33 mm in length and 17 mm in height and width, providing a compact footprint for PCB integration. The leads are 6 mm long and 1 mm in diameter made of wire type terminals ensuring easy installation.
With a very low dissipation factor of 0.0005%, the capacitor delivers high efficiency and low energy loss. It has an equivalent series resistance (ESR) of 42 mΩ and is engineered for operation between -40°C and 85°C, allowing use in demanding industrial and electronic environments.
The C4C series is metallised polypropylene film style capacitors, capable of self-healing, high ripple current, and low losses, ideal for applications such as power semiconductor circuit snubber duties, electronic ballast suppression, blocking, clamping, coupling and decoupling in motor circuits.
Rated for 3 kV DC and 750 V AC voltage for robust performance. Features ±5% capacitance tolerance for precise electrical characteristics. Plastic case ensures durability with compact dimensions. Suitable for high frequency applications and electronic ballasts.
Compliant with EN 61071, IEC 61071, VDE 0560 standards. Wire lead terminals simplify PCB mounting. Operating temperature range from -40°C to 85°C for reliability. Ideal for industrial, laboratory, and automotive electrical component use.
This film capacitor is packaged in a bag and is a new product made in India. It offers a reliable solution for engineers and manufacturers requiring stable and high voltage film capacitors.
Explore more Film Capacitors and electronic components at EnvMart to find the perfect match for your industrial, laboratory, or manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance value of this film capacitor is 22 nF with a tolerance of ±5%.
This model is rated for a DC voltage of 3 kV and an AC voltage of 750 V.
The operating temperature range for this capacitor is from -40°C to 85°C.
The capacitor has a length of 33 mm and a height and width of 17 mm each.
It features a through hole mount type for secure PCB installation.
The lead length is 6 mm with a diameter of 1 mm.
The equivalent series resistance (ESR) is 42 mΩ.
It conforms to the standards EN 61071, IEC 61071, and VDE 0560.
The dissipation factor is 0.0005%, ensuring high efficiency.
This model is suitable for applications such as voltage peak suppression in electronic and motor circuits, including snubber duties and coupling.
It is equipped with wire type terminals for easy soldering.
This film capacitor is manufactured in India.
