TDK Flange EMC Filter 35 A 520V AC 50Hz 60Hz Screw 3 Phase B84143A0035R106

Free Delivery in India | Lowest Global Shipping Charges

TDK Flange EMC Filter 35 A 520V AC 50Hz 60Hz Screw 3 Phase B84143A0035R106



Category Electronic Components Brand TDK Condition New

Specifications

Country of Origin	China
Brand	TDK
Height	71mm
Length	200mm
Model	B84143A0035R106
Depth	72.5mm
Packaging	Tray
Mount Type	Flange
Operating Frequency	50, 60Hz
Series	B84143A*R106
Maximum Operating Temperature	100°C
Number Of Stages	1
Resistance	1.7mΩ
Minimum Operating Temperature	-25°C
Maximum Current	35A
Number of Phases	3
Leakage Current	3.4mA
Maximum Voltage	520V ac
Standards/Approvals	UL1283
Termination Style	Screw
Applications include	Frequency converters for motor drives (e.g. elevators, pumps, conveyor systems and HVAC systems), Power supplies, Textile machines, Packaging machines and Machine - tools

Key Features

Compact metal case with flange mount for easy installation.
Optimized for long motor cables and full load operation.
High insertion loss reduces electromagnetic interference.
Leakage current rated at 3.4 mA ensures energy efficiency.
Suitable for frequency converters, power supplies, and industrial machinery.
Operates effectively in temperatures ranging from -25°C to 100°C.
Resistance is low at 1.7 mΩ for minimal power loss.
Compliance with UL 1283 and IEC 60939 standards guarantees quality and safety.

Product Description

TDK B84143A0035R106 Flange EMC Filter is a high-performance 3-phase power line filter designed for industrial electronic systems. It operates at a maximum current of 35 A and a maximum voltage of 520 V AC, supporting frequencies of 50 Hz and 60 Hz. The screw termination and flange mount ensure secure and easy installation in industrial environments.

The filter features a compact metal case optimized to handle long motor cables and full-load operation, offering high insertion loss to effectively reduce electromagnetic interference (EMI). Its low leakage current of 3.4 mA contributes to energy efficiency and reliable performance.

Constructed to withstand operating temperatures from -25°C up to 100°C, this filter is suitable for various demanding industrial applications. With dimensions of 200 mm length, 71 mm height, and 72.5 mm depth, it fits well in constrained spaces while maintaining robustness.

The resistance of 1.7 mΩ ensures minimal power loss during operation. Its compliance with international standards such as UL 1283, CSA 22.2 No.8, and IEC 60939 underscores its reliability and safety in diverse environments. The IP20 rating protects the device against solid foreign objects above 12 mm, suitable for indoor industrial use.

This filter is commonly employed in frequency converters for motor drives found in elevators, pumps, conveyor systems, HVAC systems, power supplies, textile machinery, packaging machines, and machine tools. Its design prioritizes ease of installation and long-term durability under demanding conditions.

Compact and durable metal case with flange mounting. Optimized for use with long motor cables and full load operation. High insertion loss for effective EMI reduction. Low leakage current of 3.4 mA. Wide operating temperature range from -25°C to 100°C.

Complies with UL 1283, CSA 22.2 No.8, and IEC 60939 standards. IP20 protection suitable for industrial indoor environments. Dimensions: 200 mm × 71 mm × 72.5 mm (L×H×D). Low resistance of 1.7 mΩ reducing power loss. Ideal for frequency converters, motor drives, and various industrial machines.
