TDK Standard Metal Oxide Varistor 180 pF 50 A Clamping Voltage 2970 V Varistor Voltage 1100 V B72214S0681K101

TDK B72214S0681K101 Standard Metal Oxide Varistor is designed to protect electronic circuits from voltage surges and spikes, featuring a capacitance of 180 pF and a clamping current capacity of 50 A. It is constructed with a ceramic body coated with epoxy resin for enhanced durability and thermal stability, suitable for industrial electrical and electronics applications.

The varistor has a clamping voltage of 2970 V, making it effective in withstanding transient overvoltages. The typical varistor operating voltage is 1100 V, suitable for AC and DC protection requirements with maximum AC voltage of 1100 V and DC voltage up to 1465 V.

Its physical dimensions include a diameter of 15.5 mm, length of 44 mm, thickness and depth of 8 mm each, and a lead pitch of 7.5 mm which ensures standard leaded mounting compatibility. The operational temperature range from -40°C to 85°C guarantees functionality across industrial environments.

The product boasts an energy rating of 1 Joule and a maximum surge current of 4.5 kA, delivering capable protection in surge-prone electrical systems. The tinned-copper wire leads facilitate easy soldering and mounting.

Certified to international standards IEC, CSA, VDE, UL, and CQC, this varistor provides reliable surge suppression for industrial power supplies, control systems, and electronic equipment.

Its robust metal oxide construction lends to longevity and stable performance in harsh usage scenarios common in manufacturing, power distribution, and electronics manufacturing sectors.

Clamping voltage is rated at 2970 V. Varistor voltage is 1100 V for surge protection. Constructed with metal oxide material and epoxy-coated ceramic body. Suitable for lead mount applications with tinned copper wire leads.

Operates reliably between -40°C to 85°C temperature range. Diameter measures 15.5 mm and length 44 mm with 8 mm thickness. Energy rating of 1 Joule providing robust surge absorption. Complies with IEC, CSA, VDE, UL, and CQC standards for quality and safety.

Maximum AC voltage rating of 1100 V and DC voltage of 1465 V. Lead pitch set at 7.5 mm ensuring compatibility with standard PCBs. Explore more in our Electronics Components and Surge Protection categories at EnvMart to find compatible Varistors and accessories for your industrial and laboratory requirements.
